Gateways

NT−52P is a compact universal−I/O PoE control gateway, capable of plug and play deployment over customer Ethernet LAN for remote control of customer−controlled devices via two universal I/O ports. The ports can be configured as bidirectional RS−232, crossed RS−232, RS−485, IR, GPI/O or relay control connections. Multiple control clients can be IP−connected to NT−52P control gateway for concurrent control of devices, such as AV scalers, video projectors and displays, audio amplifiers, DVD players, sensors, screens, shades, door locks, and lighting.

• Innovative Universal I/O Ports — Remote IP–based control of any device connected to the control gateway universal I/O ports, with selectable port configuration to bidirectional RS–232, RS–232 cross, RS–485, IR, GPI/O or relay control. Each port is adaptable for any room device control simply by toggling a button.
• Multiple IP Connected Clients — Remotely connected over customer Ethernet network, concurrently controlling any devices connected to control gateway universal I/O ports.
• Easy & Reliable Installation — With single PoE cable for both, powering and connectivity, and Plug and Play IP installation with dynamic (DHCP) address resolution and auto device discovery over customer LAN. Highly–resilient powering with multiple power options — Power over Ethernet per IEEE 802.3af standard, and PSU. Compact, designed for piggy–back installation, such as behind a TV or display, with the ability to draw power from device USB port and Ethernet connectivity.
• Remote Management — Built–in web UI for remote browser–based management and support, by multiple IP–clients over customer LAN. Easy firmware upgrades, either remotely via customer LAN, or locally via device USB port.

FC−7P is a compact GPIO/relay multi−function control gateway with Power over Ethernet, capable of plug and play deployment over a customer Ethernet LAN for remote GPI/O and relay control of customer devices. Multiple control clients can be IP−connected to the FC−7P control gateway for concurrent control of devices such as lights, shades and screens.

• Dual–Function I/O Ports — Remote IP–Based control of devices connected to the control gateway dual–function I/O ports, with selectable port configuration to bidirectional GPIO or relay control.
• Multiple IP Connected Clients — Remotely connected over customer Ethernet network, concurrently controlling any devices connected to control gateway universal I/O ports.
• Easy & Reliable Installation — With single PoE cable for both, powering and connectivity, and Plug–and–Play IP Installation with dynamic (DHCP) address resolution and auto device discovery over customer LAN. Highly–resilient powering with multiple power options — USB, Power over Ethernet per IEEE 802.3af standard, and optional PSU (not included). Compact, designed for piggy–back installation, such as behind a TV or display, with the ability to draw power from device USB port and Ethernet connectivity.
• Remote Management — Built–in web UI for remote browser–based management and support, by multiple IP–clients over customer LAN. Easy firmware upgrades, either remotely via customer LAN, or locally via device USB port.

The FC−26 is a PoE−powered control gateway, capable of plug and play deployment over a customer Ethernet LAN for remote control of customer controlled devices via bidirectional RS−232 and IR control connections. Multiple control clients can be IP−connected to the FC−26 control gateway for concurrent control of two RS−232 and four IR controllable devices, such as AV scalers, video displays, audio amplifiers, and DVD players.

• 2 RS–232 Bidirectional Control Ports — Control a device via bidirectional serial control protocols.
• 4 IR Emitter Control Ports — Control a device via IR control protocols.
• 1 Ethernet Control Port — Remote protocol–based control port.
• Built–in Web Pages — Remote browser–based control and support.
• Simultaneous IP Control Communication — With up to 40 IP control clients.
• IR Sensor Port — Learns commands from IR remotes.
• Mini USB Port — For firmware upgrades and local technical services.
• PoE Support — Per IEEE 802.3af standard.


The FC−24ETH is an Ethernet control gateway, capable of plug and play deployment over a customer Ethernet LAN for remote control of customer controlled devices via bidirectional RS−232 or RS−485 serial control connections. Multiple control clients can be IP−connected to the FC−24ETH control gateway for concurrent control of two RS−232 or RS−485 controllable devices, such as AV scalers, video displays, and audio amplifiers.

• 1 RS–485 or RS–232 Selectable Bidirectional Control Port — Controls a device via bidirectional serial control protocols.
• 3 RS–232 Bidirectional Control Ports — Control devices via bidirectional RS–232 serial control protocols.
• 1 Ethernet Control Port — Remote protocol–based control port.
• Built–in Web Pages — Remote browser–based control and support.
• Simultaneous IP Control Communication — With up to 40 IP control clients.
• Mini USB Port — For firmware upgrades and local technical services.
• Easy Installation — Plug & play IP auto–setup deployment for simple and cost–reducing installation.

The FC−22ETH is an Ethernet control gateway, capable of plug and play deployment over customer Ethernet LAN for remote control of customer controlled devices via bidirectional RS−232 or RS−485 serial control connections. Multiple control clients can be IP−connected to the FC−22ETH control gateway for concurrent control of two RS−232 or RS−485 controllable devices, such as AV scalers, video displays, and audio amplifiers.

• 1 RS–485 or RS–232 Selectable Bidirectional Control Port — Controls a device via bi–directional serial control protocols.
• 1 RS–232 Bidirectional Control Port — Controls a device via bidirectional RS–232 serial control protocols.
• 1 Ethernet Control Port — Remote protocol–based control port.
• Built–in Web Pages — Remote browser–based control and support.
• Simultaneous IP Control Communication — With up to 40 IP control clients.
• Mini USB Port — For firmware upgrades and local technical services.
• Easy Installation — Plug & play IP auto–setup deployment for simple and cost–reducing installation.

FC−6 is an RS−232/IR multi−function control gateway, capable of plug and play deployment over a customer Ethernet LAN for remote bidirectional RS−232 and IR emitter control of customer devices. Multiple control clients can be IP−connected to the FC−6 control gateway for concurrent control of two RS−232 or four IR controllable devices, such as AV scalers, video displays, audio amplifiers, and DVD players.

• Dual–Function I/O Ports — Remote IP–Based control of devices connected to the control gateway dual–function I/O ports, with selectable port configuration to bidirectional RS–232 or IR control.
• Multiple IP Connected Clients — Remotely connected over customer Ethernet network, concurrently controlling any devices connected to control gateway I/O ports.
• Easy & Reliable Installation — Plug and Play IP installation with dynamic (DHCP) address resolution and auto device discovery over customer LAN. Resilient powering with USB and optional PSU (not included). Compact, designed for piggy–back installation, such as behind a TV or display, with the ability to draw power from a device USB port.
• Remote Management — Built–in web UI for remote browser–based management and support, by multiple IP–clients over customer LAN. Easy firmware upgrades, either remotely via customer LAN, or locally via device USB port.
• Pico TOOLS™ — Mount 4 units side–by–side in a 1U rack space with the recommended rack adapter.

The FC−28 is a PoE−powered control gateway, capable of plug and play deployment over customer Ethernet LAN for remote control of customer controlled devices via bidirectional RS−232, IR, GPI/O and relay control connections. Multiple control clients can be IP−connected to the FC−28 control gateway for concurrent control of two RS−232,four IR controllable devices, such as AV scalers, video displays, audio amplifiers, DVD players, sensors, screens, shades, door locks, and lighting.
