Flat Panel Mounts

The e·Box^® II Mobile Stand is our electrically height adjustable motorized mount for displays and mobile touchscreen stands with the highest quality standards. Our motorized mount display is one of the fastest and safest technology on the AV market today. Choose an e·Box^® II Mobile Stand if you want to increase your mobility and it is convenient to move your touchscreen from one location to another.

The double-column design guarantees the stability needed to work with interactive touchscreens up to 98” diagonal with a 309 lbs (140 kg) total weight capacity. The wired remote control unit (no batteries) can be placed at a convenient and easy to reach location, allowing the user to adjust the height of the screen safely and quietly. The motorized stand has a dual anti-collision feature to prevent accidental pinching. When the system is moving and senses an obstruction, it will stop and retreat.

On the backside of the integrated vesa mounting box (with universal pattern) it is possible to lock the e·Box^® with an optional lockable rear cover. This way the electronic controls are safely located, the back side can be used to place a mini-PC, thin-client PC or NUC.

The 25.6” travel will guarantee full screen access for all users, which makes the interactive display mounting solution ideal for small, tall or wheelchair users. With the optional accessories the e·Box^® can be equipped for use with a laptop or keyboard tray, teleconferencing equipment or a document camera.

The e·Box^® II Wall Mount is our electrically height adjustable wall mount for displays and mobile touchscreen stands with the highest quality standards. Our motorized mount display is one of the fastest and safest technology on the AV market today.

The double-column design guarantees the stability needed to work with interactive touchscreens up to 98” diagonal with a 440.9 lb (200 kg) total weight capacity. The wired remote control with 3 programmable presets (no batteries) can be placed at a convenient and easy to reach location, allowing the user to adjust the height of the screen safely and quietly. The motorized mount display has a dual anti-collision safety feature to prevent accidental pinching: when the system is moving and senses an obstruction, it will stop and retreat. The premium motor is the best in its class and has a soft start / stop feature for smooth operation.

The e·Box^® consists of a Top-Box design: the backside of this integrated VESA mounting box (with universal pattern) has room for cable management and a power strip. This way the electronic controls are safely located, the backside can be used to place a mini-PC, thin-client PC or NUC.

The 25.6" (650 mm) low reach travel will guarantee full screen access for all users. The clever design and features offers maximum accessibilty, perfectly suitable for wheelchair users. With the optional accessories our solution can be equipped for use with video conferencing equipment, a document camera and a side mounting laptop or keyboard tray.

The SmartMount® Articulating Wall Arm series offers the most versatile installation features and mounting options. The I-Shaped Adaptor plate’s innovative design helps avoid blocking connections on back of display. Vertical adjustment ability allows for post installation leveling, making it easier than ever to find the perfect display position.

With SA752PU, extend the display up to 26.47" (672mm) or fully-retract it to just 2.97" (75mm) from the wall for the perfect viewing position. The display can now simply be installed by a single person with the Hook-and-Hang™ system. One-Touch™ tilt technology offers 15°/-5° vertical tilt movement for the ideal viewing angle. Integrated cable management protects, contains and conceals cables for a clean installation.

• Universal mount accommodates 200 x 100 to 600 x 400mm VESA mounting patterns
• Retracts to hold display just 2.97"(75mm) from the wall
• Extends up to 26.47" (672mm)
• ±90° degrees of pivot allows for perfect display positioning
• Easy leveling ±5° after display installation
• Quick and easy, Hook-and-Hang^TM one-person installation
• Landscape or Portrait mounting options increases display versatility
• I-shaped adaptor plate helps avoid blocking connections on back of display
• 15°/-5° vertical tilt movement for the ideal viewing angle
• Single stud wall plate design increases electrical and cable management options
• Includes all necessary wall and display attachment hardware
• Design is UL listed and tested to four times stated load capacity
• Integrated cable management protects, contains and conceals cables for a clean, professional installation
• Mounts to wood stud, concrete, cinder or breeze block

Peerless-AV’s SmartMount® Motorized Height Adjustable Stand/Wall Mount was designed to safely mount, raise and lower an interactive display. UL recognized actuators allow the user to raise or lower a display, up to 25.6" (650mm), with the touch of a button. The highly stable design can rest on the floor, or be bolted directly to either the floor or wall. The rear wall plate provides access to mount a Peerless-AV® surge protector or a mini PC, and the bottom shelf provides an area to store a digital pen or eraser. This unique mounting surface allows various users the ability to comfortably interact with a display, making it an ideal solution for education settings.

• Pre-assembled base provides rigidity, stability and quick assembly
• Center of display is adjustable from 34"-60" from the floor
• Display adaptor fits from 200 x 200 to 800 x 600mm mounting patterns
• Safety limit switch automatically reverses direction and stops when a collision is detected in an upward, downward or lateral force
• Display height can be adjusted up to 25.6" (650mm) with the touch of a button
• Textured black powder coat finish helps hide finger prints and dust
• Rear storage provides up to 29”W x 13.5”H x 4”D storage for mini PCs, such as Dell Optiplex Micro, HP 260 G2, Lenovo M600 Tiny, or Intel NUC
• Support cover hides hardware and doubles as a small shelf for digital pens and erasers
• Leveling legs allow the stand to be positioned properly, even on unlevel surfaces

The SmartMount® Universal Flat Wall Mount series offers the most versatile installation features and mounting options. Horizontal and vertical adjustment abilities allow for post installation leveling and side-to-side positioning, making it easier than ever to find the perfect TV position. The SF650(P) models’ low-profile design offers the sleek, aesthetically pleasing look to fit into any décor. Security screws provided in the SF650 models deter tampering and theft. The open wall plate design offers total wall access, increasing the electrical and cable management options. The display can now simply be installed by a single person with the Hook-and-Hang™ system. The Easy-Glide™ adaptors hook onto the wall plate for an overall quick, simple, and secure installation.

• RoHS Compliant
• TAA Compliant

The SR560M SmartMount® Flat Panel Cart has been redesigned to include all of the features you may need, making it perfect for any application. Mobility, appealing design, display height adjustment and a pre-assembled base ensure quick assembly, while providing a rigid, but attractive structure that fits into any décor. The 4" casters make it easy to move from room to room while the UL® certification ensures you that it can be done with safety in mind.

• Integrated cable management protects, contains and conceals cables for a clean, professional installation
• Pre-assembled base provides rigidity, stability and quick assembly
• Textured black powder coat finish helps hide finger prints and dust
• Universal display adaptor fits mounting patterns from 200 x 200mm to 600 x 400mm and allows mounting in landscape or portrait orientation
• Cart includes (4) plastic base pads for instances when casters are not needed

The SmartMount® Universal Tilt Wall Mount series offers the most versatile installation features and mounting options. Horizontal and vertical adjustment abilities allow for post installation leveling and side-to-side positioning, making it easier than ever to find the perfect TV position. Lock the tilt angle at installation to prevent tampering or moving with the IncreLok™ tilt technology. Security screws provided in the ST640 models deter tampering and theft. The open wall plate design offers total wall access, increasing the electrical and cable management options. The display can now simply be installed by a single person with the Hook-and-Hang™ system. The Easy-Glide™ adaptors hook onto the wall plate for an overall quick, simple, and secure installation.

• Universal mount fits displays with mounting patterns up to 458 x 405mm (18.02" W x15.95" H) and accommodates up to 400 x 400mm VESA patterns
• Adjustable 15° forward tilt and 5° Backward tilt for finding the optimal viewing angle
• For mounts requiring standard hardware, installed with a Philips screwdriver, please purchase ST640P
• Easy-Grip^TM ratcheting handle locks tilt angle into place
• Up to 0.25" (6mm) of vertical adjustment on each universal display adaptor bracket for post-installation leveling and height adjustment fine-tuning
• Horizontal display adjustment up to 6.00" (152mm) for centering display on wall
• Landscape to Portrait mounting options increases installation versatility. Please check display dimensions against the wall plate when used in Portrait mode*
• Includes all necessary wall and display attachment hardware
• Integrated security options available
• Design is UL listed and tested to four times stated load capacity

Description

The SmartMount® Universal Tilt Wall Mount series offers the most versatile installation features and mounting options. Horizontal and vertical adjustment abilities allow for post installation leveling and side-to-side positioning, making it easier than ever to find the perfect TV position. Lock the tilt angle at installation to prevent tampering or moving with the IncreLok™ tilt technology. Security screws provided in the ST650 models deter tampering and theft. The open wall plate design offers total wall access, increasing the electrical and cable management options. The display can now simply be installed by a single person with the Hook-and-Hang™ system. The Easy-Glide™ adapters hook onto the wall plate for an overall quick, simple, and secure installation.

Specifications

• Universal mount fits displays with mounting patterns up to 742 x 405mm (29.21" W x 15.95" H) and accommodates up to 600 x 400mm VESA patterns
• Adjustable 15° forward tilt and 5° backward tilt for finding the optimal viewing angle
• Easy-Grip^TM ratcheting handle locks tilt angle into place
• Up to 0.25" (6mm) of vertical adjustment on each universal display adaptor bracket for post-installation leveling and height adjustment fine-tuning
• Horizontal display adjustment up to 8.00" (203mm) for centering display on wall
• Includes all necessary wall and display attachment hardware
• Integrated security options available
• Design is UL listed and tested to four times stated load capacity
• For mounts requiring theft resistant hardware, installed with security tool (included), please purchase ST650
• For mounts requiring standard hardware, installed with a Philips screwdriver, please purchase ST650P

The Peerless-AV® FPZ-670 Flat Panel Floor Stand is designed to support up to two 90" displays, mounted back-to-back, in either landscape or portrait orientation. The attractive, yet robust and functional, stand is ideal for a wide variety of applications and settings from boardrooms, training rooms and lobbies, to classrooms, auditoriums and exhibition halls. Its appearance is complemented by a sturdy base, with a concealed compartment to house media players and surge protectors, while its internal cable management system conceals cables and cords, delivering a clean look for any application.

Features

• VESA® 200 x 200mm compliant
• Supports additional VESA® patterns with PLP display adaptor (sold separately)
• Hook-on design allows display to rest in place while display is being secured
• Portrait or landscape display orientation
• Height adjustable on 72” (1829mm) poles

This universal mobile stand by QOMO features a heavy duty steel frame and an adjustable VESA mount for displays up to 105" diagonal. The lockable casters allow for easy mobility with built-in shelf for convenient placement of laptops and multi-media players.

BalanceBox® is a manually operated height adjustable mount based on a patented spring tension technology. Unique, fast and user-friendly as no electric connection is needed. The BalanceBox® manual mounts gives you ultimate comfort, is extremely reliable and safe. Choose any preferred position of your interactive display and find out how fast and easy you can move it to any position you like. Together with the flat panel wall mount or the flat panel mobile stand and the accessories you prefer, we offer a total solution for your interactive display.

The BalanceBox® 400 manual height adjustable mount is the perfect solution to move your touch screen up and down. The BalanceBox® 400 has a weight capacity up to 95 kg (209 lbs) and a compact design with a black textured finish.

Make a choice between a wall mount solution, the perfect solution for the wall in your classroom or conference room, and the mobile stand model QBB400-Mobile-e, when it is more convenient to move your touchscreen around inside the room or from from one room to another. Interface brackets for all screen sizes, a floor support and a mobile frame are available as accessories.

For large and heavy interactive flat panels up to 98", and heavy and wide constructions

BalanceBox® is a manually operated height adjustable mount based on a patented spring tension technology. Unique, fast and user-friendly as no electric connection is needed. The BalanceBox® manual mounts gives you ultimate comfort, is extremely reliable and safe. Choose any preferred position of your interactive display and find out how fast and easy you can move it to any position you like. Together with the flat panel wall mount or the flat panel mobile stand and the accessories you prefer, we offer a total solution for your interactive display.

The BalanceBox® 650 is the perfect manual height adjustable wall mount solution to move larger and heavier interactive touch panels up and down with the touch of a finger. This patented height-adjustable wall mount has a weight capacity up to 279 lbs in a compact design. Make a choice between a flat panel wall mount solution a perfect solution for your wall in your classroom or conference room. Or select a flat-panel mobile stand, model QBB650-Mobile when it is more convenient to move your touchscreen from one room to another.

One of the things that makes work easier is working with the e·Box® Tilt & Table electrical height adjustable mount. The e·Box® Tilt & Table makes working with a touchscreen far more easy. It is an innovation which makes it possible to change the position of the touchscreen from vertical (the normal upright position) to horizontal (the table position) and any diagonal position in between. This makes the e·Box® Tilt & Table electrical mounting solution the perfect solution for all users to work on their own height in a group or as an individual.

The double-column design guarantees the stability needed to work with Interactive Touchscreens up to 75” diagonal with a 220 Lbs (100 kg) total weight capacity. The wired remote control unit (no batteries) can be placed at a convenient and easy to reach location, allowing the user to adjust the height and tilt angle of the screen safely and quietly. The motorized stand has an anti-collision feature on the height adjust motors to prevent accidental pinching: when the system is moving and senses an obstruction, it will stop and retreat.

The height adjust motor is the fastest in its class at 1.5”per second travel speed (38 mm per second) and has a soft-start and soft-stop. VESA interfaces for dimensions 400x200 up to 600x400 are integrated in the support frame for the touch panel. On the topside of the columns there is an enclosed box where the electronic controls are safely located, this lock-box can be used to place a mini-PC, thin-client PC or NUC.
The 26” travel will guarantee full-screen access for all users, while the 90 degree tilt feature will allow multiple users to access the screen at the same time (depending on the touchpanel specifications) the product is ideal for wheelchair users.
