Telephone, email, and live chat troubleshooting, diagnostic, and programming support for Dukane clock systems. Consult with a factory-certified technician with over a decade of experience working on Dukane communications systems.

Price is per incident, per hour. No other parts or materials are included. Photos are for illustrative purposes only.

About Dukane Wired Clock Systems

Dukane Communication Systems proposes a simple solution – get in sync! Dukane’s family of analog and digital clocks combined with programmable master clocks and other accessories makes keeping and controlling time easier. Dukane can provide turnkey systems including clocks and controllers to keep your facility running on the same schedule, day after day

By synchronizing the clocks within a facility, you ensure that all personnel inside have the same information. No matter the type of environment, things run more smoothly if the time is accurate and consistent.

Some applications, like elementary schools, require analog clocks. Others, like higher education, businesses, and healthcare facilities, prefer digital versions. Dukane offers both analog and digital models and Dukane has priced these clocks to be the most competitive available today.

To simplify installation, Dukane’s clock system components can use standard electrical backboxes rather than custom or proprietary versions. This means that Dukane's clocks can be installed into most existing wall openings.

With the flick of a dip switch, our analog clock can take on the personality of various other syncronous secondary clocks. All you need is our analog clock for all your replacement needs.

Clocks should be easy to find and easy to read, while fitting into their surroundings. Dukane's clocks are styled to be simple, clearly visible, and neutral to their environment. Architects and engineers will appreciate their adaptability.

Dukane offers unique scoreboard and timer capabilities when using the 24CC10 Controller with digital clocks. These can be useful when there is a need to time tests, keep score between teams, or even determine how long certain tasks take to complete.

Dukane's clock systems deliver the accuracy, choices, convenience, styling, and unique features that your facility is looking for, all at a price you can afford.

About Dukane Wireless Clock Systems

Dukane wireless clock solutions comprise a reliable master/slave cascading network that synchronizes clocks from a central on-site master controller. The master clock receives highly accurate time signals from an NTP or GPS source and relays timecodes to local slave clocks via wireless signals.

Each clock in the system is capable of receiving and transmitting the wireless signal which allows it to be used as a repeater while boosting the data stream and sending along the system. With this dual capability there is no limit to the number of clocks that can be installed throughout highrises, sprawling facilities, and small buildings alike.

Because the signal fans out and is repeated by a cascading number of devices, a single clock will typically receive its data from a number of different angles. This dramatically reduces the effect of obstructions, noise sources, or long distances on the reliability of the system. Furthermore, if an individual clock looses its signal, it will link to a nearby clock and automatically synchronize with that new source.

The cascading network also reduces system setup and installation costs, thanks to the relatively low signal strength that is necessary for it to function efficiently. This eliminates the expense and time required to obtain an FCC license.

The Dukane Model 24ZB20 and 24ZB40 Secondary Clocks provide a highly visible, even-intensity, long-life display of time in selectable formats. They can be operated in either 12- or 24-hour format, and at either Bright or Normal intensity levels. The time display on the secondary clock updates to the master clock time at one-minute intervals. These cost-effective digital clocks can be used in a wired time-keeping system or, with the addition of the optional ZigBee module 24ZBM2040, can be installed on a wireless system.

Description

TOAlert, an EverAlert emergency communication platform, is a comprehensive, innovative visual display and campus-wide notification system that supports and extends routine, institutional messaging and emergency notifications. It is compatible with our N-8000 Intercom & VM-3000 Mass Communication Systems, and delivers the functions of three systems in one - keeping building occupants safe, informed, and on-time.

EverAlert Dynamic Display is a Smart 22” class HD screen with built-in speakers. The EverAlert platform supports a virtually unlimited number of displays in either a landscape or portrait orientation. It is preloaded with an operating system software, which communicates to the inCloud management portal through wired ethernet or Wi-Fi network. Additionally, the display is able to resume normal operation without intervention after a temporary power interruption.

Specifications

• Dimensions: master shipping carton, two displays .........................38” L, 8-3/8” W, 18-1/2” H
• Weight: master shipping carton, two displays ....................................37lbs
• Weight: single (device only) ...........................................................................8lbs
• Dimensions: single (device only) ................................................................20 13/16” L, 1-3/8” W, 12 9/16” H
• Dimensions: display screen diagonal ......................................................21.5”
• Lighting: screen ...................................................................................................LCD with LED backlight
• Resolution: display screen .............................................................................1920 x 1080
• Mounting formats ...............................................................................................Landscape (horizontal) or portrait (vertical)
• Internal speakers ................................................................................................2 each at 2W
• USB 2.0 ports .......................................................................................................2
• External speaker output jack .......................................................................3.5mm
• Wired LAN connectivity ..................................................................................10/100M, RJ45 connector
• Wireless LAN connectivity ............................................................................802.11b/g/n (2.4GHz)
• USB provisioning ................................................................................................USB drive with AES encryption
• Wired provisioning .............................................................................................LAN/DHCP Web portal on network connection
• Time synchronization support ....................................................................2 static IP address SNTP servers
• Clock battery backup for power outages .............................................CR1220 lithium
• Maximum relative humidity ...........................................................................85%
• Operating temperature ....................................................................................32˚F – 104˚F
• Input voltage to power supply .....................................................................100-240VAC, 50/60Hz
• Output voltage from power supply ...........................................................12VDC
• Energy efficiency ................................................................................................Level VI
• Power Consumption .........................................................................................25W (average), 40W (maximum), 20W (sleep)
• Certifications ........................................................................................................ROHS, CE/FCC, PSU with UL

Features

• Smart 22” class HD screen with built-in speakers
• EverAlert platform supports a virtually unlimited number of displays
• Display functions in either landscape or portrait orientation
• Preloaded with operating system software
• Communicates to the inCloud management portal through wired Ethernet or Wi-Fi network
• Resumes normal operation without intervention after a temporary power interruption
• Operator adjustable or scheduled screen brightness
• Scheduled sleep mode for energy conservation
• 1 year warranty

Adapter plate allowing standard two tab mounting clocks to be mounted with single screw anchor. Typically used for batter powered clocks with no need for an electrical box. Fits low profile steel 12” round clocks (LR- 12XX).

Description

The National Time PS-3, PS-6, PS-12 Power Supplies are designed to compliment National Time's Master Clocks with low voltage digital and/or analog clocks. Each offers power limited transformer(s) with individual circuit breakers to allow less costly Class 2 wiring installations. Each transformer can supply 3.12A of 24VAC. For 2- wire clock systems, each transformer supports a clock circuit, while for 3-wire systems one transformer supplies 'run' power while another supplies the 'reset' power for a clock circuit. The power supplies may be converted to Remote Power Boosters with the addition of the optional PS-Relays. Each power supply is housed in a durable steel enclosure designed to match National Time's Master Clocks and create an integrated and attractive installation.

PS-3:

One 3.12A 120/24VAC Transformer will support one 2-wire clock circuit. Order one PS-Relay to create circuit booster supply. 9"x8"x4" Enclosure. Two knockouts each side.

PS-6:

Two 3.12A 120/24VAC Transformers will support either two 2-wire clock circuits, or one 3- wire clock circuit. Order one PS-Relay to create a dual circuit 2-wire booster, or two PS-Relays to create a 3- wire circuit booster supply. 9"x8"x4" Enclosure. Two knockouts each side.

PS-12:

Four 3.12A 120/24VAC Transformers will support either four 2-wire clock circuits, or two 3- wire circuits. Order one PS-Relay to create a quad circuit 2-wire booster, or two PS-Relays to create a dual 3-wire circuit booster supply. 12"x12"x4" Enclosure. Two knockouts top and bottom.

Features

• 120VAC/24VAC Power Supply
• UL Recognized Power-Limited Isolation Transformers
• Individual Circuit Breakers
• Durable Steel Enclosure
• Integrated System Look
• Flush and Surface Mount Versions
• Made in the U.S.A.
