2-Channel Dante Audio Analog Encoder

Description

Blustream DA11AEN has been designed to encode unbalanced or balanced 2ch analog audio to Dante digital signal.

The DA11AEN allows any non-Dante audio source such as mixing consoles, amplifiers, computers and Blustream matrix products or distribution products to be connected as a source within a Dante network.

The DA11AEN is a plug & play device that is powered using PoE (Power over Ethernet) from any PoE network switch and supports AES67 RTP audio transport.

Features

• Encodes unbalanced or balanced 2ch analog audio to a Dante digital signal
• Supports 44.1, 48 & 96 KHz sample rates @ 24 Bit
• Configurable Dante device latency (supports 1, 2 or 5ms configurable using Dante Controller)
• Supports AES67 RTP audio transport
• Features Class 1 802.3af PoE for powering of product from any PoE switch
• Local 12v power supply input for when network switch does not support PoE * PS121PH power supply sold separately

Specifications

• Audio Input Connectors: 6-pin Phoenix connector (2ch balanced / un-balanced analog audio)
• Audio Output Connectors: 1 x RJ45, female (100Mbps Dante network)
• Casing Dimensions (L x W x H): 4.72 x 1.85 x 1.02"
• Shipping Weight: 0.44lb
• Operating Temperature: 32°F to 104°F
• Storage Temperature: -4°F to 140°F
• Power Supply: Class 1 IEEE 802.3af POE PD

Item Includes

• 1x DA11AEN
• 1x Quick Reference Guide

• Model: DA11AEN
• Manufacturer:
