Kramer

VP−551X is a versatile, professional presentation scaler/switcher for 4K@60 (4:4:4) HDMI, VGA and composite video signals. The unit scales the video and provides options to use the embedded HDMI audio or to select the companion audio channel from one of ten analog audio input signals. After processing and scaling, the embedded AV signal is sent to the HDMI and the HDBaseT outputs simultaneously, and the audio is also sent to a balanced stereo audio output, S/PDIF digital output and a pair of loudspeakers.

• High–Performance Switcher/Scaler — Scales HDMI, VGA and Composite video signals for output to two mirrored outputs: HDMI and HDBaseT. Constant output sync prevents signal disruption when switching between inputs and when no video is detected.
• High–Resolution Video — Supports and scales to/from resolutions up to 4K@60Hz (4:4:4) on the HDMI inputs and output, and 4K@60Hz (4:2:0) on the HDBaseT output. Complies with HDCP 2.2. Supports HDR10, CEC, xvYCC color (on input), Dolby TrueHD/DTS–HD Master Audio (by–pass), as specified in HDMI 2.0.
• Professional Video Quality — Provides selectable aspect ratios (full, best fit, over scan, under scan, letter box and pan scan). Includes built–in ProcAmp for color, hue, sharpness, noise, contrast and brightness control. Supports PixPerfect™, Kramer’s precision pixel mapping and high–quality scaling technology. High–quality 3:2 and 2:2 pull–down de–interlacing and full up–scaling and down–scaling of all video input signals.
• Versatile Audio Options — Includes a companion analog audio input for each of the 10 video inputs, enabling the user to embed a separate analog audio channel into each video signal or to bypass an embedded audio input (for example, to support multi–channel, compressed audio formats like Dolby and DTS). Provides 2 independent microphone inputs on 6.3mm connectors (each with optional 48V phantom power) for mixing, switching or talk–over. On the output, besides the audio embedded on HDMI and HDBaseT outputs, the audio signal is also extracted (de–embedded) and output as balanced stereo analog audio, and as digital audio through an S/PDIF connected device, as well as amplified to 20W per channel for connection to loudspeakers.
• Powerful Audio Features — Includes DSP with audio equalization, mixing, delay and more.
• Versatile Powering Options — Receives power from a universal power supply (100–240V AC) and provides PoE power to a compatible HDBaseT device.
• HDTV Compatible.
• 4K and Legacy Inputs — 8 4K@60 (4:4:4) HDMI inputs, 1 VGA input, and 1 CV (composite video) input.
• Non–Volatile Memory — Saves final settings before shutdown and retains them for next power up.
• Convenient Control Options — Local control via front panel buttons (input selection, audio mute, freeze and front panel lock), RS–232, IR remote, and OSD. Long–distance control via Ethernet using embedded web pages.
• Easy Installation — 19” enclosure for rack mounting a unit in a 1U rack space with included rack ears and universal 100–240V AC power connection.

• Max. Resolution — 4K@60Hz (4:4:4)

Kramer’s C−A35M/A35M mini audio cable is constructed from high−quality shielded pair style cable terminated with molded male 3.5mm stereo connectors on both ends.

• Quality Construction — Constructed from flexible, high–quality 28AWG cable for transparent performance with line level audio signals.
• Varied Selection of Lengths — Available in versions of 3 to 100ft (0.9 to 30.5m).

Description

VIA Connect² is a smart, secure, wireless and wired presentation and collaboration platform that makes it simple to get actual work done during meetings and classes. With any laptop or mobile device, users can view, edit, and comment on documents in real time sessions. Meeting participants can display or stream full, uninterrupted video up to 4K@60Hz from their device, and even play YouTube® videos in full frame rate. Up to four participants can share their screens simultaneously on the main display either using the VIA app mirroring feature, iOS mirroring via AirPlay™, Windows & Android mirroring via Miracast™, or ChromeBook mirroring.

VIA Connect² supports 3rd party conferencing and apps, such as Microsoft Teams®, and Zoom®. The platform can handle most small to medium size meeting spaces and is ideal for classrooms and huddle spaces. VIA Connect² is super−compact (74x74mm) and flexible to install with both built−in Wi−Fi and LAN connectivity and includes industry−leading 1024−bit encryption for secure use on the internal network.

Features

• Quick and Reliable Wireless Connectivity — A simple and intuitive user interface enables iOS™, Android™, Chromebook™, PC, and Mac™ device users to instantly connect to a main display. 2.4GHz/5GHz Wi–Fi and MIMO antennas establish and maintain a fast and reliable connection.
• Clientless Connectivity — Airplay, Miracast, Join Through Browser.
• Up to 4K@60 HDMI Wired Input — Enables hard–wiring, auto switching, for connecting a computer or any HDMI compatible device camera, multimedia player or computer that supports HDCP signals.
• Powerful Security Feature — 802.1x User authentication, 1024–bit encryption, dynamic room code.
• Built–In Wi–Fi and LAN.
• Comprehensive Collaboration Functionality — Whiteboard, filesharing, View Main Display, chat, etc.
• High–Quality Video Streaming — Supports up to 4K@60Hz resolution using the VIA app Multimedia feature.
• Simultaneous Display — Four participants can simultaneously present content on the main display.
• Seamless Live Video Streaming — Stream live content from meeting rooms, classrooms and studios using RTMP/RTMPS to all the leading platforms, like YouTube™, Kaltura™, Panopto™ and more.
• Optimized for Video Conferencing — VIA Versa feature allows users to wirelessly connect to the professional grade camera and AV in their meeting spaces easily and instantly.
• Wireless USB — Supports Microphone, Speaker & Camera.
• Built–in Third Party VC integration for Zoom™ & Teams™.
• Cloud–Based Management — Seamlessly compatible with VIA Site Management (VSM).
• Easy and Flexible Installation — With a super–compact form factor, it can be discreetly installed on the back of a display, projector or almost anywhere.

Applications

• Hybrid work and hybrid education environments
• Presentation environments
• Small to mid–size meeting rooms
• Classrooms

Included In the Box

Included: Power adapter, Video Switching control cable, VESA mount

KWC−1 (Kramer Wireless Charging) is a built−in table mounted charging spot that enables you to charge your mobile device by simply placing it on the charging spot. It mounts flush with the table surface for an unobtrusive wireless charging solution.

If your mobile device does not feature wireless charging, you can connect it to a charging dongle (sold separately) and then place it on the charging spot.

• Elegant in–Table Solution
• Easy to Install — Drill a hole 4.17" to 4.25" (106 to 108mm) in tables less than 3" (76mm) thick.
• Qi Standard Compliant

Description

WP−SW2−EN7/US−D(W) is an advanced wall plate encoder for streaming 4K@60Hz (4:2:0) video signals via Ethernet over copper cable.

• Video Streaming Transmitter — Streams up to 4K@60Hz (4:2:0) resolution signals over a 1G network interface.
• HDR — Supports HDR10 up to 4K@30Hz 4:2:2 12bits.
• Streaming Support — Unicast and multicast.
• Multiple Inputs — One HDMI input and one USB–C input, which support multiple switching policy including Last connected, Priority and Manually.
• Analog Audio Embedding — Embed the unbalanced analog audio into the streaming and HDMI output signal.
• Convenient and Comprehensive Control — Control the unit using intuitive web interface, protocol 3000 API commands via Ethernet, or front panel LCD and navigation buttons.
• Control Gateway — Through P3K or special TCP connection, user can control/communicate with RS232, CEC to the connected devices.
• PoE Support — Option to power with PoE connection from a PoE switch.

Applications

• For real–time essential installations such as command and control rooms
• For large scale AV content sharing installations using existing wires and infrastructure in corporate offices and government applications
• AV distribution systems with one or more sources and many displays in schools, universities, and public venues
• For AV installations where low latency KM/KVM capabilities are required

Description

WP−DEC7US−D(W) is an advanced decoder for streaming 4K@60Hz (4:2:0) video signals via Ethernet over copper cable.

• Video Streaming Receiver — Streams up to 4K@60Hz (4:2:0) resolution signals over a 1G network interface.
• HDR — Support HDR10 up to 4K@30Hz 4:2:2 12bits.
• Streaming Support — Unicast and multicast.
• Analog Audio De–Embedding Output — Extract the HDMI audio or LAN streaming audio and output it as balanced analog audio.
• Convenient and Comprehensive Control — Control the unit using intuitive embedded web pages, Protocol 3000 API commands via Ethernet or front panel LCD and buttons.
• Control Gateway — Through P3K or special TCP connection, user could control/communicate with RS232 and CEC to the connected devices.
• Video Wall — Up to 16x16 size.
• PoE Support — Option to power with PoE connection from a PoE switch

Applications

• For real–time essential installations such as command and control rooms
• For large scale AV content sharing installations using existing wires and infrastructure in corporate offices and government applications
• AV distribution systems with one or more sources and many displays in schools, universities, and public venues
• For AV installations where low latency KM/KVM capabilities are required

Kramer’s C−A35M/2RAM is a simple adapter which has a stereo 3.5mm connector at one end, and two male RCA connectors at the other. It provides passive conversion between 3.5mm and dual RCA connectors, most often adapting a PC sound card or MP3 player to the audio inputs of a sound system or display device.

• Quality Construction — Molded male dual RCAs on one end and molded 3.5mm on the other.
• High–Quality Connectors — RCA connectors are color coded red, white to match audio connectors on typical equipment.

VS−48UHD is a high−quality 4x8 matrix switcher for 4K@60Hz (4:2:0) HDMI signals and embedded audio. It reclocks and equalizes the signals and can route any one of four HDMI, HDCP−compliant sources (selectable) to any or all outputs simultaneously. VS−48UHD offers a flexible audio scheme where any HDMI digital audio input can be routed to any HDMI digital audio output in addition to ARC support to produce an equivalent 12x10 audio matrix.

• Max. Data Rate — 8.91Gbps data rate (2.97Gbps per graphics channel).
• Max. Resolution — 4K@60Hz (4:2:0).
• Independent 12x10 Audio Matrix — With 4 embedded digital inputs + 8 ARC inputs and 8 digital outputs + 2 ARC outputs.
• Kramer Step–In Over HDMI Technology.
• HDMI, HDCP and DVI Compliance.
• Selectable HDCP Off per Input.
• Memory Locations — 12 presets for quick access to common configurations.
• Advanced EDID Management per Input.
• Active Source & Acceptor Detection.
• Automatic Input Selection — Based on priority selection or last connected input.
• Firmware Upgrade — Via mini USB, Ethernet or the RS–232 port.
• HDMI Support — Deep Color, 3D, ARC, up to 7.1 uncompressed audio channels.
• Kramer reKlocking™ and Equalization Technology — Rebuilds the digital signal to travel longer distances.
• Embedded Pattern Generator — With selectable patterns.
• Lock Button — To prevent tampering.
• Kramer Protocol 3000 Support.
• Control Options — RS–232 serial commands transmitted by a PC, touch screen system or other serial controller, Ethernet port via LAN, embedded Web pages via LAN for configuration and control.
• Size — Standard 19" (1U). Rack "ears" included

Kramer's BC-UNIKAT cable is a unified CAT6a cable that handles all Pro AV and IT signals. Over four individually screened twisted pairs, this U/FTP CAT6A cable runs Kramer’s DGKat™ technology, 4K HDBaseT™ technology or LAN applications and ensures optimal signal performance.

• Quality Construction — 4 shielded twisted pairs (U/FTP) of 23AWG solid copper conductors are cabled together in an unshielded outer jacket.
• Optimized for Kramer Hardware
• HDBaseT Recommended — www.hdbaset.org/hdbaset–recommended–cables/.
• Reaction to Fire Classification — Dca–s2,d1,a1 (optional: B2ca–s1,d1,a1).
• RJ–45 Connector — The larger diameter 23AWG twisted pair cable requires a special RJ–45 connector

Kramer's BC−XTP unshielded twisted pair (UTP) cable is designed as the ideal companion to Kramer analog twisted pair transmitter−receiver sets. BC−XTP resembles typical CAT 5e, but with internal components optimized for transmission of video/audio signals rather than high−speed data.

• Quality Construction — Durable and flexible bulk cable. Four pairs of 24AWG solid copper.
• Optimized for High–res Video/Audio Signals — Four pairs are twisted at the same ratio so the actual length of each is identical. Video shift or “skew” is eliminated in long runs because the RGB color signals arrive at the same time. Note that BC–XTP is not suited for high–speed data or network applications.
• Optimized for Kramer Hardware — Use with any of Kramer’s wide range of twisted pair transmitter–receiver sets such as PT–110/PT–120, WP–110/PT–120, etc. Terminate with RJ–45 connectors, or strip and attach to terminal strips or punchdown blocks as needed.
• Length — Available in pull boxes of 100/300m (328/985ft).

Kramer’s C−MDP/HM/UHD enables you to connect your Mini DisplayPort™ equipped PC or laptop to an HDMI display with no additional adapters or cables required.

This active Mini DisplayPort to HDMI cable is used for true conversion when the source does not support DP++ and can be used in either DisplayPort single−mode or dual−mode outputs.C−MDP/HM/UHD supports up to 4K@60 (4:4:4) video resolution and HDCP 2.2.

• Supported Resolutions — Up to 4K@60Hz (4:4:4).
• Plug and Play Installation — No driver is required.
• Active DisplayPort to HDMI Conversion.

CA−HM active HDMI copper cable provides a perfect cable solution for delivering HDMI signals over long distances: 18Gbps up to 20m (66ft) and 10.2 Gbps up to 30m (98ft). The innovative technology utilized in the cable’s connector features superior equalizing and signal compensation to meet the most demanding challenges in Pro AV installations.

This unique solution simplifies long distance installations by using a true plug & play cable that draws power from the HDMI source. There is no need for an external power source.

CA−HM features the Kramer exclusive K−Lock HDMI connector, that prevents cables in your installation from unintentionally disconnecting, eliminating cable−related service calls. Additionally, an LED on the connector indicates when the signal is transmitted successfully.

• Video Resolution — Up to 4K@60Hz (4:4:4).
• High Data Transfer Rate — Up to 18Gbps.
• HDMI Support — HDCP 2.2, HDR, EDID, ARC and CEC.
• Deep Color, x.v.Color™, 5.1/7.1 lossless Dolby TrueHD and DTS–HD surround sound.
• High–quality Connectors — 24K gold–plated, corrosion–resistant connectors offer the best possible connectivity.
• Pull–resistant — K–Lock connectors with 15 lbs. of restraining force.
• Triple Shielded — For maximum EMI protection.
• UL Listed — CL3/FT4 rated for in–wall installations.

• Max. Resolution — 4K@60Hz (4:4:4).

Kramer's C−HM/HM cable is your default choice for high−performance, HDMI cable.It supports signals up to 4K@60Hz (4:4:4), Deep Color, x.v.Color™, Lip Sync, 7.1 PCM, Dolby TrueHD, DTS−HD, CEC.

• Quality Performance — Kramer’s HDMI cables provide an uncompressed digital link between consumer electronics equipment such as DVD players, set–top boxes and audio/video monitors such as LCD or OLED display screens for high–definition TVs.
• Max. Resolution — 4K@60Hz (4:4:4).
• High–Quality Connectors — 24K gold–plated connectors resist corrosion, and offer the best possible connectivity.
• K–Lock Pull–Resistant Connectors — Provides 15lbs of restraining force for a non–slip connection.

Kramer's C−HM/HM/ETH HDMI cable is a high−performance cable with molded HDMI connectors at both ends. It supports Ethernet Channel, Deep Color, x.v.Color™, Lip Sync, 7.1 PCM, Dolby TrueHD, DTS−HD, CEC and ARC and resolutions up to 4K@60Hz (4:4:4).

• Quality Performance — Kramer’s HDMI cables provide an uncompressed digital link between consumer electronics equipment such as DVD players, set–top boxes and audio/video monitors such as plasma display screens for high–definition TVs.
• Max. Resolution — 4K@60Hz (4:4:4).
• High–Quality Connectors — 24k gold–plated connectors resist corrosion, and offer the best possible connectivity.
• K–Lock Pull–Resistant Connectors — Provides 15lbs of restraining force for a non–slip connection.

Kramer's C−HM/HM/PRO HDMI cable delivers high−speed, high−performance digital video and audio with impeccable impedance stability, low skew, high signal integrity, and noise immunity for up to 4K@60Hz (4:4:4). With pro−grade heavy−duty construction, triple−shield bonded pairs and K−Lock connectors, PRO series cables are robust and reliable for the most demanding applications.

• Max. Data Rate — 18Gbps.
• Max. Resolution — 4K@60Hz (4:4:4).
• Deep Color — Supports 24–bit, 30–bit, 36–bit and 48–bit (RGB or YCbCr) color depths. Best for multimedia applications or home cinema and surround systems.
• Multi–Channel Audio Support — Supports audio stream for external decoding by AV receivers and automatic audio syncing capabilities.
• High Quality Connectors — 24K gold–plated, corrosion–resistant and best possible connectivity.
• K–Lock Pull–Resistant Connectors — Provides 15lbs of restraining force for a non–slip connection.
• Shield — Triple overall shield against EMI/RFI interference

Kramer's C−MDP/DPM cable is an ideal solution for connecting the Mini DisplayPort or Thunderbolt output of a small laptop or tablet to a computer monitor that accepts a DisplayPort input. This cable carries a digital audio/video signal, supports up to 4K@60Hz (4:4:4) resolution and is built to DisplayPort 1.2 standards.

• Video Resolution — Supports up to a 4K@60Hz (4:4:4) resolution with a maximum HBR2 bandwidth of 21.6Gbps.
• Standards Compliance — DisplayPort 1.2.
• Gold Plated Connectors.

Kramer’s C−HM/HM/FLAT/ETH flat high−speed HDMI cable with Ethernet is designed for “invisible” and long distance installations. It routes through the wall, under the carpet, around corners and behind the entertainment system with ease. The flat design of the cable renders it unobtrusive. It supports resolutions up to 4K@60Hz (4:4:4).

• Quality Construction — Constructed from flexible flat cable structured to have less crosstalk and interference than with traditional round HDMI cables.
• Max. Resolution — 4K@60Hz (4:4:4).
• High–Quality Connectors — 24K gold–plated connectors resist corrosion, cut down on impedance and offer the best possible connectivity.
• K–Lock Pull–Resistant Connectors — Provides 15lbs of restraining force for a non–slip connection.

Mini DisplayPort (M) to HDMI (M) Cable

C−DP is a high−resolution DisplayPort cable for video signals up to 4K@60Hz (4:4:4) resolution supporting DisplayPort 1.2 standard. C−DP supports an HBR2 (High Bit Rate 2) bandwidth of up to 21.6 Gbps. The cable is triple shielded for superior noise immunity.

• High–Performance Professional Cable — supports resolutions up to 4K@60Hz (4:4:4) and an HBR2 (High Bit Rate 2) bandwidth of up to 21.6 Gbps.
• Content Protection Support — DPCP (DisplayPort Content Protection) and HDCP 2.2.
• Daisy Chain Multiple Monitors — With MST (Multi–Stream) support.
• Secure Connections — Includes molded DisplayPort connectors with latches.
• Quality Construction — Triple shielded for superior noise immunity.
• Backward Compatibility — Compatible with DisplayPort 1.1.

Kramer's C−MDPM/MDPM is a flexible DisplayPort cable. It is a high−performance cable with molded connectors at both ends that supports resolutions up to 4K@60Hz (4:4:4).

• Max. Resolution — 4K@60Hz (4:4:4).
• Unique Thin and Flexible Cable — Ideal for use with Kramer TBUS products and rack building.

Kramer’s C−DPM/HM/UHD enables you to connect your DisplayPort™ equipped PC or laptop to an HDMI display with no additional adapters or cables required.

This active DisplayPort to HDMI cable is used for true conversion when the source does not support DP++ and can be used in either DisplayPort single−mode or dual−mode outputs.C−DPM/HM/UHD supports up to 4K@60Hz (4:4:4) video resolution and HDCP 2.2.

• Supported Resolutions — Up to 4K@60Hz (4:4:4).
• Plug and Play Installation — no driver is required.
• Active DisplayPort to HDMI Conversion.

• Compatibility — Requires a dual–mode DisplayPort device that implements both HDMI and DisplayPort signals. These devices are usually identified with the DP++ logo.

Kramer’s C−MGMA/MGMA is a micro sized, high−performance cable for computer graphics and audio with slim molded 15−pin HD and 3.5mm connectors at both ends. This micro coax cable is thin and flexible and is an excellent choice for connecting computer graphics video and audio signals between computers or video scalers and plasma, LCD or other popular display technologies.

• Quality Construction — Constructed using micro coax conductors and outer diameter of 6.0mm (0.236in). The 15–pin HD connectors are specially designed with a small profile to fit any high density installation and all 15 pins are passed through the cable. The audio leads are 61.0cm (24in) long at one end and 20.3cm (8in) on the other end.
• Multiple Applications — Ideal for video presentations, home theater and any installation in tight spaces. Use these cables with our table solutions for your convenience and efficiency.
• All Pins Connected for DDC2 and EDID Support.

Kramer’s C−MGM/MGM Micro computer graphics video cable is a high−performance cable with molded 15−pin HD connectors on both ends. This micro coax cable is thin and flexible and is an excellent option for connecting computer graphics video signals between computers or video scalers and plasma, LCD or other popular display technologies.

• Quality Construction — Constructed using micro coax conductors, with an outer diameter of 5.4mm (0.212in). The 15–pin HD connectors are specially designed with a small profile to fit any high–density installation and with all 15 pins passing through the cable.
• Multiple Applications — Ideal for video presentations, home theater and any installation in tight spaces. Use these cables with our table solutions for a convenient and efficient installation.
• All Pins Connected for DDC2 and EDID Support.

Kramer’s C−GMA/GMA is a high−performance cable with male 15−pin HD and 3.5mm stereo audio connectors at each end. It is perfect for computer graphics video to display installations that require an audio signal as well.

• Quality Construction — Constructed using our rugged and flexible 14–conductor cable.
• Easy Connection — Pre–terminated with molded 15–pin HD connectors (male to male), gold–plated pins and thumbscrews and a 3.5mm stereo mini jack.
• Easy Installation — Audio leads extend 24in (61cm) beyond the 15–pin HD head at one end, and 20cm (8in) at the other.
• All Pins Connected for DDC2 and EDID Support.

VS−411UHD is an automatic switcher for 4K@60Hz (4:2:0) HDMI and analog audio signals. VS−411UHD automatically switches one of four HDMI inputs to a predefined or last connected input whenever the currently active video signal is interrupted or whenever a higher−priority video signal is detected. They also support Kramer’s Step−in over HDMI technology.

• Max. Data Rate — 8.91Gbps (2.97Gbps per graphic channel).
• Max. Resolution — 4K@60Hz (4:2:0).
• Compliance — HDCP and DVI 1.0.
• Deep Color, 3D, up to 7.1 uncompressed audio channels, ARC (supported on Input 1 only).
• Features Kramer reKlocking™ Technology — Rebuilds the digital signal to travel longer distances.
• HDTV Compatible.
• Customized Audio Output — Embed a companion analog audio signal into its HDMI input signal, de–embed the audio from the HDMI input and route it to the balanced stereo audio line out, de–embed HDMI ARC from the output and route it to the balanced stereo audio line out, or route the analog audio inputs directly to the stereo audio line out.
• Automatic Video Input Detection & Selection.
• Auto Power Off — When no HDMI input for 10 seconds (selectable).
• Step–In Over HDMI Technology.
• Active Switching — Selectable manual or fast auto switching according to last connected or preset priority.
• Selectable HDCP Switching.
• EDID Configuration Options.
• Default EDID.
• Contact Closure — For remote manual switching override.
• Lock Button
• Firmware Upgrade — Over RS–232, mini–USB.
• Software Support — Protocol 3000, EDID Designer, K–Upload via RS–232.
• Varied Control Options — Front panel buttons, contact closure, IR, RS–232 Protocol 3000.
• Easy Installation — Compact MegaTOOLS® fan–less enclosure for surface mounting or side–by–side mounting of 2 units in a 1U rack space with the recommended rack adapter.

The VS−211UHD is an automatic switcher for 4K@60Hz (4:2:0) HDMI and analog audio signals. The VS−211UHD automatically switches one of two HDMI inputs to a predefined or last connected input whenever the currently active video signal is interrupted or whenever a higher−priority video signal is detected.

• Max. Data Rate — 8.91Gbps (2.97Gbps per graphic channel).
• Max. Resolution — 4K@60Hz (4:2:0).
• Compliance — HDCP and DVI 1.0.
• Deep Color, 3D, up to 7.1 uncompressed audio channels, ARC (supported on Input 1 only).
• Features Kramer reKlocking™ Technology — Rebuilds the digital signal to travel longer distances.
• HDTV Compatible.
• Customized Audio Output — Embed a companion analog audio signal into its HDMI input signal, de–embed the audio from the HDMI input and route it to the balanced stereo audio line out, de–embed HDMI ARC from the output and route it to the balanced stereo audio line out, or route the analog audio inputs directly to the stereo audio line out.
• Automatic Video Input Detection & Selection.
• Auto Power Off — When no HDMI input for 10 seconds (selectable).
• Step–In Over HDMI Technology.
• Active Switching — Selectable manual or fast auto switching according to last connected or preset priority.
• Selectable HDCP Switching.
• EDID Configuration Options.
• Default EDID.
• Contact Closure — For remote manual switching override.
• Lock Button.
• Firmware Upgrade — Over RS–232, mini–USB.
• Software Support — Protocol 3000, EDID Designer, K–Upload via RS–232.
• Varied Control Options — Front panel buttons, contact closure, IR, RS–232 Protocol 3000.
• Easy Installation — Compact MegaTOOLS® fan–less enclosure for surface mounting or side–by–side mounting of 2 units in a 1U rack space with the recommended rack adapter.

The VP−444 is a high−performance presentation scaler/switcher for HDMI and computer graphics signals. The unit scales the video, embeds the audio, and outputs the signal to two HDMI (with embedded audio) outputs (with S/PDIF and balanced stereo audio) simultaneously.

• Kramer’s PixPerfect™ Scaling Technology — Kramer’s precision pixel mapping and high–quality scaling technology. High–quality 3:2 and 2:2 pull down de–interlacing and full up and down scaling of all video input signals.
• HDTV Compatible.
• HDCP Compliant.
• Video Inputs — 10 HDMI & 2 computer graphics video on 15–pin HD connectors.
• Scaled Outputs — 2 HDMI.
• 22 Output Resolutions — Up to WUXGA/1080p.
• 2 Microphone Inputs — For mixing, switching or talk–over (with 48V phantom selection).
• Auto Input Scanning and Switching.
• Companion AFV (Audio–Follow–Video) — Stereo audio for every input (on terminal blocks).
• Audio Inputs — 12 unbalanced stereo on terminal blocks & embedded audio for HDMI inputs, each with individual level controls.
• Audio Outputs — 1 S/PDIF on an RCA connector, 1 balanced stereo audio on a terminal block, embedded audio on the HDMI outputs.
• Multiple Aspect Ratio Selections — Full, overscan, underscan, letterbox & panscan.
• Audio DSP — Powerful digital audio signal processing, including audio equalization, mixing, delay, etc.
• Built–in ProcAmp — Color, hue, sharpness, noise, contrast & brightness.
• Color Sampling — Supports 4:4:4 (RGB and YUV) as well as 4:4:2 (YUV) color sampling.
• Constant Output Sync — No disruption on the output while switching between inputs and when no video is detected.
• Front Panel Control — Audio mute & freeze frame.
• Built–in Web Pages.
• Front Panel Lockout.
• Non–Volatile Memory — Saves final settings.
• Flexible Control Options — Front panel, IR remote with OSD (on–screen display), Ethernet with built–in Web pages & RS–232.
• Worldwide Power Supply — 100–240V AC.

The VS−211HA is a high−performance automatic standby switcher for HDMI video and unbalanced stereo audio signals. The VS−211HA can be used as a manual 2x1 switcher or automatic switcher. The switcher uses a priority input or last connected input.

VM−3DT is a high−quality, long−reach 4K@60Hz (4:2:0) HDBaseT extender distributor that takes one long−reach HDBaseT input, equalizes and reclocks the signal and distributes it to three identical HDBaseT outputs. VM−3DT distributes native HDBaseT signals with up to 4K video resolution, along with their re−extension over HDBaseT.

• High Performance Distribution — Distributes one native, long–reach HDBaseT signal to three outputs with up to 4K video resolution, along with their re–extension over HDBaseT.
• Dual–side Extension — Extends a 4K@60Hz (4:2:0) 24bpp (maximum) video signal to a distance of up to 40m (130ft) long–reach, and even further for lower video resolutions, when deployed mid–way between an AV source and multiple remote acceptors using CAT copper cable.
• Standard Compatibility — Connects to any HDBaseT compliant extension product on the market.
• HDMI Signal Transmission — HDCP 1.4 compliant signal, supporting deep color, x.v.Color™, lip sync, 7.1 PCM, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0. EDID and CEC (OUT 1 only) signals are passed through from the source to the display.
• I–EDIDPro™ Kramer Intelligent EDID Processing™ — An intelligent EDID handling, processing and pass–through algorithm that ensures Plug and Play operation for HDMI source and display systems.
• LED Indicators — Status indicators for HDBaseT input/output connected signals and power for ease of maintenance and troubleshooting.
• Easy Installation — Twisted–pair cables for HDBaseT signals wiring. Standard half–width 19” rack (1U) enclosure for side–by–side mounting of 2 units in a 1U rack space.

The VM−1H4C is a high−quality 1:4 twisted pair distribution amplifier for HDMI signal to PoC Long−reach DGKat signals. The unit receives serial commands and IR signals transparently via the RS−232 port and the TP link. It reclocks and equalizes the input signal and distributes it to four DGKat TP outputs.

• Max. Data Rate — 4.95Gbps (1.65Gbps per graphic channel).
• HDTV Compatible.
• HDCP Compliant.
• DGKat™ Signal Integration — Kramer’s unique technology for converting TMDS as well as control and communication to signals that run over twisted pair cables.
• EDID Pass–through — Pass–through algorithm ensures Plug and Play operation for HDMI source and display systems.
• HDMI Support — x.v.Color™ and uncompressed audio channels, Dolby TrueHD, DTS–HD.
• 3D Pass–Through.
• Kramer Equalization & re–Klocking™ Technology — Rebuilds the digital signal to travel longer distances.
• System Range — Up to 90m (295ft) at 1080i @60hz or up to 70m (230ft) at 1080p @ 60hz when using Kramer DGKat cables. Note: Transmission range depends on the signal resolution, graphics card and display used. If using third–party shielded CAT cables, both ends of the shield must be soldered to the connectors for the products to function properly.
• Power Connect — The VM–1H4C provides power to the twisted pair receivers when they are within 270ft (90m) of the transmitter.
• Active Input & Output LED Indicators.
• Serial Command Handling — Receives serial commands transparently via the RS–232 port and the TP link.
• Desktop Size — Compact size. 2 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.

VP−429H2 is a 4K@60Hz (4:4:4) scaler / switcher tool for HDMI, DisplayPort, VGA, and unbalanced audio signals. The unit scales the signal and outputs it on HDMI. Step−In functionality provides easy plug−and−play collaboration when connected to a switcher that supports Step−in over HDMI. It also features convenient RS−232 control of monitor or projector activation and supports Ethernet, contact closure switches and RS−232 control.

• High–Performance Switcher/Scaler — Scales signals of all standard resolutions up to 4K (4:4:4) HDMI HDCP 2.2 for output to the HDMI output. Constant output sync prevents signal disruption when switching between inputs and when no video is detected. Supports Deep Color, x.v.Color™ and 3D as specified in HDMI 2.0.
• Superior Switching and Signal Control — Select automatic switching options using live input detection, enable or disable HDCP per input, copy and save the EDID to the inputs (supported on HDMI and DisplayPort inputs), and define output refresh rate and aspect ratio.
• Local Step–In Switching — When used with a Step–In enabled switcher, just plug in your device and press the Step–In button or use the contact closure Step–In switch. Your device becomes the active signal on the main display.
• Diverse Inputs — 2 HDMI (4K@60Hz (4:4:4)), 1 DisplayPort and 1 VGA input.
• Cost–Effective and Convenient Control Options — Local control via front panel input selection buttons and setup DIP–switches, Ethernet with embedded web pages, RS–232 serial ports for control of the unit and of a display via the unit, and GPI controls.
• Easy Installation — Compact MegaTOOLS® fan–less enclosure for surface mounting or side–by–side mounting of 2 units in a 1U rack space with the recommended rack adapter.

• Max. Data Rate — 6.75Gbps (2.25Gbps per graphic channel).
• HDCP Compliant.
• HDTV Compatible.
• HDMI Support — Deep Color, x.v.Color™, Lip Sync, up to 7.1 Uncompressed Audio Channels.
• 3D Pass–Through.
• EDID Capture — Copies and stores the EDID from a display device.
• Dual Mode — PC and DVD Modes selectable by input.
• Flexible Control Options — Front panel, RS–232 (K–Router™ Windows®–based software is included), Ethernet & IR remote (available upon request) .
• Video Disconnect.
• Front Panel Lockout.
• Worldwide Power Supply. — 100–240V AC.
• Standard 19” Rack Mount Size. — 1U. Rack "ears" included.

WP−789R is a high−performance, long−reach HDBaseT wall−plate receiver for 4K@60Hz (4:2:0) HDMI and HDCP 2.2 signals over twisted pair. It converts the transmitted HDBaseT signal into an HDMI signal. It extends video signals up to 40m (130ft) over Kramer copper cables at 4K@60Hz (4:2:0) 24bpp video resolution and provides even further reach for lower HD video resolutions. This wall−plate is powered through PoE (Power over Ethernet) over the twisted pair cable.

• High Performance Receiver — Professional HDBaseT receiver for providing long–reach signals over twisted pair copper infrastructures. WP–789R is a standard extender that can be connected to any market–available HDBaseT–compliant extension product. For optimum extension reach and performance, use recommended Kramer cables.
• Reliable PoE (Power over Ethernet) Powering — Auto–senses the extension line PoE status, and accepts power from a remote PoE provider such as a PoE matrix, with optional mains powering from connected power adapter.
• HDMI Signal Extension — Supports HDCP 2.2, deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0.
• EDID Pass–through — Pass–through algorithm ensures Plug and Play operation for HDMI source and display systems.
• Multi–channel Audio Extension — Up to 32 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
• Low Profile Wall–Plate — Designed for elegant, in–wall deployment behind a wall–mounted flat panel display. Minimizes the depth of the installation, especially when connected with a Kramer right–angle HDMI cable.
• Cost–Effective Maintenance — Power and connectivity status LED indicator facilitates easy local maintenance and troubleshooting.
• Easy Installation — Fits into standard US, EU and UK 2–gang in–wall box size, supporting decorative integration with room deployed user interfaces such as electrical switches. Wall–plate installation is fast and cost–effective via a single twisted pair cable, providing both video signal and power (PoE) connections.

WP−871xr is a high−performance, long−reach DGKat™ 2.0 wall−plate transmitter for 4K@60Hz (4:4:4) HDR HDMI and HDCP 2.2 signals and power over twisted pair. It converts the HDMI input signal into a DGKat™ 2.0 signal and transmits it to a compatible receiver. WP−871xr extends the signal to up to 60m (200ft) at 4K@60Hz (4:4:4) resolution and up to 70m (230ft) at 4K@30Hz (4:4:4) 24bpp resolution over Kramer shielded cables. This wall−plate is powered through PoC (Power over Copper) over the twisted pair cable.

• High Performance Transmitter — Professional DGKat™ 2.0 transmitter for providing long–reach signals over twisted pair copper infrastructures. WP–871xr transmitter employs high–level video compression technology that delivers visually lossless performance for 4K@60Hz (4:4:4) HDR signals with near–zero latency. It converts the HDMI input signal into a DGKat™ 2.0 signal and transmits it to a compatible receiver.
• HDMI Signal Extension — HDR, HDCP 2.2 compliant. Supports deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0.
• EDID Pass–through — Pass–through algorithm ensures Plug and Play operation for HDMI source and display systems.
• Multi–channel Audio Extension — Up to 32 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
• Cost–Effective Maintenance — Power and connectivity status LED indicator facilitates easy local maintenance and troubleshooting.
• Easy Installation — Compactly fits into standard US, EU and UK 1–gang in–wall box size, supporting decorative integration with room deployed user interfaces such as electrical switches. Wall–plate installation is fast and cost–effective via a single twisted pair cable, providing both video signal and power (PoC) connections.

The VP−445 is a high−performance presentation scaler/switcher for HDMI, computer graphics and composite video signals. The unit scales the video and gives you an option to embed HDMI or analog audio. Then it sends the signal to two HDMI outputs and S/PDIF and balanced stereo audio outputs simultaneously.

• Max. Resolutions — Up to UXGA/1080p.
• HDTV Compatibility.
• PixPerfect™ Scaling Technology — Kramer’s precision pixel mapping and high–quality scaling technology. High–quality 3:2 and 2:2 pull–down de–interlacing and full up — and down–scaling of all video input signals.
• 12 Video Inputs — 6 HDMI on HDMI connectors, 4 computer graphics video on 15–pin HD connectors and 2 composite video on RCA connectors.
• Two HDMI Scaled Outputs (Mirrored).
• 2 Microphone Inputs — For mixing, switching or talk–over.
• Companion AFV (Audio–Follow–Video) — Stereo audio for every input (on terminal blocks).
• Audio Inputs — 12 unbalanced stereo inputs on terminal blocks, embedded audio for the HDMI inputs, each with individual level controls.
• Audio Outputs — 1 S/PDIF on an RCA connector, one balanced stereo audio on a terminal block and embedded audio on the HDMI outputs.
• Powerful Audio Features — Via DSP technology including audio equalization, mixing, delay and so on.
• Multiple Aspect Ratio Selections — Full, best fit, over scan, under scan, letter box and pan scan.
• Built–in ProcAmp — Color, hue, sharpness, noise, contrast and brightness.
• Color Sampling Support — 4:4:4 (RGB and YUV) and 4:4:2 (YUV).
• Constant Output Sync — No disruption on the output while switching between inputs and when no video is detected.
• Front Panel Control — Audio mute and freeze frame.
• Front Panel Lockout.
• Non–Volatile Memory — Saves final settings.
• Various Control Options — Front panel buttons, RS–232, IR remote, OSD, Ethernet Web pages, Ethernet using UDP.
• Universal Power Supply — 100–240V AC

The 905xl is a high−performance remote−controllable power amplifier.

• Stereo Mode — 2 x 110W @4Ω.
• Selectable Balanced and Unbalanced Inputs.
• Remote Control (RS–232) — Volume, EQ and input selection.
• Class D Amplifier.

VS−21T is a high−performance selector for Ethernet and HDBaseT CAT lines. The user selected input CAT line, either Ethernet or HDBaseT, is connected to the output CAT line with its carried signal.

• Easy Input Selection — Click–to–connect manual selection using either panel or remote buttons.
• Easy Installation — Compact DigiTOOLS® fan–less enclosure for desktop or under–table mounting, or side–by–side mounting of 3 units in a 1U rack space with the recommended rack adapter.

The VP−774AMP is a high−performance presentation switcher and scaler. It accepts one of nine inputs: one DisplayPort (DP), one composite video, two computer graphics, one 3G HD−SDI and four HDMI signals. It scales the video, embeds the audio, and simultaneously outputs the signal to two identical HDMI, one HDBaseT and one 3G HD−SDI output, together with S/PDIF and balanced stereo audio outputs. The unit also includes an audio amplifier and speaker outputs.

• K–IIT XL™ Picture–in–Picture Image Insertion Technology — Ultra–stable picture–in–picture, picture–and–picture, and split screen capability. Any video source can be inserted into or positioned next to any other video source with full window positioning and sizing controls.
• Kramer’s PixPerfect™ Scaling Technology — Kramer’s precision pixel mapping and high quality scaling technology. High–quality 3:2 and 2:2 pull down de–interlacing and full up — and down–scaling of all video input signals.
• State–of–the–Art Video Processing Technology — For highest quality de–interlacing, noise reduction, and scaling performance for both standard–definition and high–definition signals.
• Ultra–Fast Fade–Thru–Black (FTB™) Switching — Video switching transitions are clean and ultra fast. The video fades to black and the new input fades from black for smooth, glitch–free switching. The output signal provides constant sync so the display never glitches.
• HDCP Compliant — The HDCP (High Definition Content Protection) license agreement allows copy–protected data on the HDMI input to pass only to the HDMI output.
• Advanced EDID Management — Per input; analyzes the EDID of a selectable Master connection to one of the outputs.
• Mass Notification Emergency Communication System (MNEC) — Activates a national or campus–wide notification, immediately displayed when an emergency situation develops. It uses automatic text overlaying, either via a crawler or a full screen cover up, as well as an optional audio alert.
• Max. Data Rate — 6.75Gbps (2.25Gpbs per graphic channel).
• Multi–Standard SDI Support — SDI (SMPTE 259M), HD–SDI (SMPTE 292M) and 3G HD–SDI (SMPTE 424M).
• Scaled Outputs — 2 HDMI, 1 HDBaseT, 1 3G HD–SDI (all outputs work simultaneously).
• Output Resolutions — HDTV and computer graphics up to 2K and 1080p/UXGA with selectable refresh rates.
• HDMI Deep Color Support — For all inputs and outputs.
• Luma Keying — Via PIP window.
• Vertical Keystone Operation.
• Built–in Proc–Amp — With enhanced functions such as color correction, gamma and dither.
• Multi–Standard Video Support — NTSC (3.58/4.43), PAL (M/N/60) and SECAM with advanced de–interlacing options.
• Built–in Time Base Corrector — Stabilizes unstable video sources.
• Picture Zooming — Both on main and PIP window from 100% to 1600%, including separate V and H sharpness control.
• Input and Output Colorspace Control.
• Audio Support — Unbalanced stereo audio inputs, with two microphone inputs; digital stereo and balanced stereo outputs; input and output audio level adjustment.
• Selectable Microphone Talkover or Mix Modes.
• Microphone Inputs — 2 dynamic or condenser (with 48V phantom voltage).
• Audio Amplifier & Speaker Output — 2x10W.
• Automatic Detection and Selection of Embedded Audio — Automatically outputs the signal from the HDMI and DP embedded audio inputs or performs an analog takeover to output the respective analog audio input.
• Range — Up to 130m (430ft) normal mode; up to 180m (590ft) ultra mode (1080p @60Hz @24bpp) when using BC–HDKat6a cables.
• On–Screen Display (OSD) — For easy setup and adjustment, accessible via the IR remote control and via the front–panel buttons.
• Built–in Web Page Server.
• Non–Volatile Memory — Saves final settings.
• Firmware Upgrades — Via Ethernet and RS–232.
• Flexible Control Options — Front panel buttons, OSD (on–screen display) via front panel buttons or IR remote (remote control included), embedded Web server.
• Port Tunneling — A bidirectional RS–232 interface where simple control commands and data can flow in both directions from a controller to the VP–773 via the Ethernet, allowing status requests and control of the destination unit
• Selectable Power Save Modes — For efficient energy use.
• Worldwide Power Supply — 100–240V AC.
• Standard 19" Rack Mount Size — 1U. Rack ears included.

The Galil 6−AW on−wall outdoor speaker features a multi−tap power transformer for selecting 8Ω (bypassing the transformer) or 70V/100V power settings, which are suitable for an array installation. Suitable for outdoor installations and applications. Available in white or black.

The Tavor 6−O is a pair of 6.5−inch powered two−way speakers designed for indoor wall mounting. The active speaker accepts a line−level stereo input and amplifies it using a built−in amplifier and outputs a speaker signal to the passive speaker.

• Active Loudspeaker — Stereo 2x50W RMS, 2x140W continuous program built–in power amplifier.
• Inputs — 1 unbalanced RCA, 1 unbalanced 3.5mm mini jack, 1 balanced on terminal block.
• Audio Level Controls — Volume, treble and bass.
• Magnetically Shielded.
• Enhanced Bass Reflex.
• Auto Power — Shuts off when system is not in use, indicated by a LED.
• Automatic Input Voltage Selector — 90 to 240V AC, 50 to 60Hz.
• Indoor Wall Mounting.
• Mounting Configuration — Active speaker: left, passive speaker: right.
• Weight (Single Speaker) — Active speaker 3.6kg (7.92lbs) approx., passive speaker 2.7kg (5.94lbs) approx.
• Package — 2 speakers (1 pair); 1 pair of U–shaped rotating mounting brackets with 4 mounting knobs; 4m (13.12ft) power cord; 4m (13.12ft) loudspeaker cable; 2m (6.6ft) 3.5mm to 2 RCA cable.

The WP−571 is a PoC DGKat™ wall plate transmitter for HDMI signals. The WP−571 converts an HDMI signal to a DGKat™ twisted pair signal that it transmits to a WP−572.

• Max. Data Rate — 4.95Gbps (1.65Gbps per graphic channel).
• HDTV Compatible.
• HDCP Compliant.
• DGKat™ Signal Integration — Kramer’s unique technology for converting TMDS as well as control and communication to signals that run over twisted pair cables.
• HDMI Support — HDMI Uncompressed Audio Channels, Dolby TrueHD, DTS–HD.
• 3D Pass–Through.
• System Range — Up to 90m (295ft) at 1080i @60hz or up to 70m (230ft) at 1080p @ 60hz when using Kramer DGKat cables.
  Note: Transmission range depends on the signal resolution, graphics card and display used. If using third–party shielded CAT cables, both ends of the shield must be soldered to the connectors for the products to function properly.
• EDID PassThru — Passes EDID signals between the source and display.
• Active Power Indication — The ON LED lights red when receiving power only, orange when either input or output and power are attached, and green when both an active input and output are attached.
• Power Connect™ System — A single connection to the transmitter or the receiver powers the system when the devices are within 90m (295ft) of each other.

Kramer's C−UNIKAT cable is a unified CAT6a cable that handles all the latest technology signals. Over four individually screened twisted pairs, this U/FTP CAT6a cable runs Kramer’s DGKat™ technology, 4K HDBaseT™ technology or LAN applications and ensures optimum signal performance.

• Quality Construction — 4 shielded twisted pairs (U/FTP) of 23AWG solid copper conductors are cabled together in an unshielded outer jacket.
• Optimized for Kramer Hardware — Use with any of Kramer’s wide range of twisted pair digital transmitter–receiver sets (DGKat™ and HDBaseT).
• High–Quality Shielded RJ–45 Connectors — 50u gold plated contacts.

VS−21TS is a high−performance selector for Ethernet and HDBaseT CAT lines. The user selected input CAT line, either Ethernet or HDBaseT, is connected to the output CAT line with its carried signal and power.

• Easy Input Selection — Click–to–connect manual selection using either panel or remote buttons.
• Reliable PoE (Power over Ethernet) Powering — Selected line remote powering is switched to input line, to provide power to its connected device.
• Easy Installation — Compact DigiTOOLS® fan–less enclosure for desktop or under–table mounting, or side–by–side mounting of 3 units in a 1U rack space with the recommended rack adapter.

The WP−572 is a PoC DGKat™ twisted pair receiver for HDMI signals. The WP−571 converts an HDMI signal to a single twisted pair signal and the WP−572 converts the twisted pair signal back to an HDMI signal.

• Max. Data Rate — 4.95Gbps (1.65Gbps per graphic channel).
• HDTV Compatible.
• HDCP Compliant.
• DGKat™ Signal Integration — Kramer’s unique technology for converting TMDS as well as control and communication to signals that run over twisted pair cables.
• HDMI Support — x.v.Color™, up to 7.1 Uncompressed Audio Channels.
• 3D Pass–Through.
• System Range — Up to 90m (295ft) at 1080i @60hz or up to 70m (230ft) at 1080p @ 60hz when using Kramer DGKat cables. Note: Transmission range depends on the signal resolution, graphics card and display used. If using third–party shielded CAT cables, both ends of the shield must be soldered to the connectors for the products to function properly.
• EDID PassThru — Passes EDID signals between the source and display.
• ON LED — Lights red when receiving power only, orange when either input or output and power are attached, and green when both an active input and output are attached.
• Power Connect™ System — A single connection to the transmitter powers the receiver.
• Dimensions — 3.3cm x 3.6cm x 10.4cm (1.3" x 1.42" x 4.1") W, D, H.
• Wall Plate Size — 1 gang US.

WXA−H1/US is a passive wall plate that includes the following inputs: 15−pin HD, 3.5mm Audio, & HDMI.

• Front Panel Connections — 15–pin HD (F), HDMI (F) and 3.5mm (F).
• Rear Panel Connections — 15–pin HD (F), HDMI (F) and 3.5mm (F).
• EDID PassThru — Passes EDID signals from source to display.
• Size — Available in 1 gang US only.
• Keystone connectors (no pigtail).

Kramer's C−D9M/D9F control cables are for RS−232 applications to control devices within a professional AV system. Many Kramer products are RS−232 controllable and equipped with 9−pin D connector. This RS−232 cable helps to connect them safely to transmit the RS−232 serial commands to a touch−screen system, PC, or other serial controller equipped with 9−pin D connector.

• Quality Construction — Constructed using three 28AWG isolated conductors, terminated with male to female molded 9–pin D–sub connectors, nickel plated.
• Pinout — Wired pin to pin on pins 2, 3 & 5.
• Molded Strain Relief.
• RoHS Compliant.

Kramer's C−D9F/OPEN control cables are for RS−232 applications to control devices within a professional AV system. Many Kramer products are RS−232 controllable and equipped with terminal block connector. This RS−232 cable helps to connect them safely to transmit the RS−232 serial commands to a touch−screen system, PC, or other serial controller equipped with D9 connector.

• Quality Construction — Constructed using three 28AWG isolated conductors, terminated with a molded female 9–pin D–sub connector, nickel plated on one side and open end, non–terminated, on the second side.
• Pinout — Wired pin to pin on pins 2, 3 & 5.
• Molded Strain Relief.
• Stripped & Tinned Wires — At open end.
• RoHS Compliant.
