KDock−6 is a USB−C hub multiport adapter and ergonomic laptop stand. It has adjustable height and positioning and is an ideal accessory for MacBooks, laptops equipped with USB Type−C and tablets. KDock−6 can connect your USB−C device to HDMI™, DisplayPort video outputs, 3 USB 3.2 Gen 1 ports, an Ethernet port, an audio and microphone port, and USB−C charging pass−through port.
The bracket and dock are affixed with magnetic suctions and buckles. Users can choose to use them separately or together according to their needs.
The laptop holder contains holes for heat dissipation and rubber sheets for easier gripping.
- Supports HDMI and DisplayPort video outputs.
- Supports USB 5G speed connection between host and docking station.
- Supports Ethernet 1Gbps.
- Includes a 3.5 mm headset jack.
- Bracket panel is layered with silicon to prevent slipping of laptop/tablet or other devices.
- Bracket and dock are affixed with a magnetic suction and buckle.
- Bracket panel is designed for better heat dissipation to prevent overheating devices.
- 6 Programmable Color, Back Lit Buttons
- Printed Group Labels
- Macro Capability
- Internal Clock
- 1 Bidirectional RS–232 — Control AV equipment
- IR Learning Function
- 2 Relay Contact Closure Ports
The RC−62 is a 6−button room controller for multimedia rooms. The unit can control audio components, video components and other room facilities such as lights and screens.
- Back Lit & Label Capable Buttons — 6 RGB–color, tactile feedback, backlit buttons. Buttons are grouped in 2 groups, 4 buttons in ‘SOURCES’ group, and 2 buttons in ‘DISPLAY’ group.
- Custom Labeled, Removable Button Caps.
- 2 K–NET™ Connectors — Connects to master room controller, and auxiliary keypads for remote keypad control.
- K–NET™ Single Link Connection — Provides a single keypad link cable–connectivity, carrying both power and keypad control communication information.
- RS–232 Control Port — Controls a device via serial control protocols.
- IR Emitter Control Port — Controls a device via IR control protocols.
- Relay Control Port — Controls a device via relay contact closure.
- IR Sensor Port — Learns commands from IR remotes.
- Program Control — Program configuration with Kramer K–Config software.
- Keypad Lock–Out — Option for tampering prevention by locking and unlocking of the keypad buttons.
- Mini USB Port — To upload configuration files, set the K–NET™ ID number, and power the device during configuration.
- Mounting — In–wall, in standard 2 gang EU, UK, and 1 Gang US wall junction boxes.
- Easy Installation — Fits to standard in–wall boxes for simple and cost–reducing installation.
Description
The RC−43SL is a touch−sensitive 6−button control keypad. Connected over Ethernet to Site−CTRL™ remote AV control, site management & monitoring system, as well as LAN−connected control gateways for extended controlled devices capacity. It also connects over KNET™ to master room controller and auxiliary keypads for remote keypad control. It can flexibly serve either as a standalone room controller, part of multi−units KNET™ system, or part of multi−unit Ethernet system managed by Kramer Site−CTRL™ site management platform. The RC−43SL is ideal for auditoriums and meeting rooms, for convenient control of their complex multimedia systems and other room facilities such as screens, lighting and shades.
Features
- Touch–Sensitive & Label Capable Buttons — 6 white–color LED–feedback buttons.
- Custom Labeled, Removable Button Caps.
- 1 K–NET™ Connector — Connect to master room controller, and auxiliary keypads for remote keypad control.
- K–NET™ Single Link Connection — Provides a single keypad link cable–connectivity, carrying both power and keypad control.
- 2 RS–232 Bi–directional Control Ports — Control a device via bi–directional serial control protocols.
- 2 IR Emitter Control Ports — Control a device via IR control protocols.
- 3 Relay Control Ports — Control a device via Relay Contact Closure, such as scrolling up and down screens, drapes, shades, and blinds.
- IR Sensor Port — Learns commands from IR remotes.
- Program Control — Program configuration with Kramer K–Config software.
- Kramer Site–CTRL™ Compatibility — For network management and remote control over the Ethernet port.
- Mini USB Port — To upload configuration files, set the K–NET™ ID number, and power the device during configuration.
- Mounting — In–wall, in standard 1 gang US wall junction boxes.
- Easy Installation — Fits to standard in–wall boxes for simple and cost–reducing installation.
The RC−63DLN is a 6−button control keypad with knob and LCD displays. Connected over KNET™ to master room controller and auxiliary keypads for remote keypad control, it can serve either as a standalone room controller or part of a multi−unit KNET™ system. The RC−63DLN is ideal for classrooms and meeting rooms, for convenient control of their multimedia devices and other room facilities such as screens and shades.
- Back Lit & Label Capable Buttons — 6 RGB–color, tactile feedback, backlit buttons. Buttons are grouped in 2 groups, 4 buttons in ‘SOURCES’ group, and 2 buttons in ‘DISPLAY’ group.
- Custom Labeled, Removable Button Caps.
- Volume Control Knob with LEDs — Bi–directional rotary dialed digital knob for volume control, with 5 LED bar for visual volume level feedback.
- 2 K–NET™ Connectors — Connects to master room controller, and auxiliary keypads for remote keypad control.
- K–NET™ Single Link Connection — Provides a single keypad link cable–connectivity, carrying both power and keypad control communication information.
- RS–232 Control Port — Controls a device via serial control protocols.
- IR Emitter Control Port — Controls a device via IR control protocols.
- Relay Control Port — Controls a device via relay contact closure.
- IR Sensor Port — Learns commands from IR remotes.
- Program Control — Program configuration with Kramer K–Config software.
- Keypad Lock–Out — Option for tampering prevention by locking and unlocking of the keypad buttons.
- Mini USB Port — To upload configuration files, set the K–NET™ ID number, and power the device during configuration.
- Mounting — In–wall, in standard 2 gang EU, UK, and US wall junction boxes.
- Easy Installation — Fits to standard in–wall boxes for simple and cost–reducing installation.
RC−208 is a compact 8−button control keypad that fits US 1−gang wall junction boxes. Easy to deploy with a single LAN cable carrying both power (PoE) and communication, it fits decoratively within a room design. It fits decoratively within a room design. It is perfectly suited for use as a user interface keypad within a Kramer Control system. Using K−Config, tap into the rich, built−in I/O interfaces that enable this keypad to be used as a flexible, standalone room controller. In this way, it is ideal for classroom and meeting room control, providing end−user convenient control of complex multimedia systems and other room facilities such as screens, lighting and shades.
Multiple keypads can be linked together side−by−side or at a distance, via a single K–NET™ cable carrying both power and communication, providing uniform design and user experience.
- Clear and Customizable User Interface — RGB–color, tactile feedback, backlit buttons with custom labeled, removable button caps, allowing simple and intuitive end–user and guest control over facility deployed devices and systems.
- Flexible Room Control — Control any room device via LAN connections, multiple RS–232 and RS–485 serial ports, and various IR, relay and general purpose I/O built–in device ports. Connect the keypad to an IP network with additional control gateways interfacing with remote controlled devices, for extending control across large space facilities.
- Expandable Control System — According to arising demands, easily expands to be part of a larger control system, or coupled–operation with auxiliary keypads, via either LAN or K–NET™ single cable connection delivering both power and communication.
- Simple Control Programming — Using K–Config software. Leverage the power of Kramer’s highly customizable, flexible and user–friendly software, to easily program complex control scenarios of Pro–AV, Lighting, and other room and facility controlled devices.
- Easy and Cost–effective Installation — Compactly fits into standard US, EU and UK 1–gang in–wall box size, allows decorative integration with room deployed user interfaces such as electrical switches. Keypad installation is fast and cost–effective via a single LAN cable providing both power (PoE) and communication connections.
RC−208 is a compact 8−button control keypad that fits US 1−gang wall junction boxes. It fits decoratively within a room design. It is perfectly suited for use as a user interface keypad within a Kramer Control system. Using K−Config, tap into the rich, built−in I/O interfaces that enable this keypad to be used as a flexible, standalone room controller. In this way, it is ideal for classroom and meeting room control, providing end−user convenient control of complex multimedia systems and other room facilities such as screens, lighting and shades.
Multiple keypads can be linked together side−by−side or at a distance, via a single K–NET™ cable carrying both power and communication, providing uniform design and user experience.
- Clear and Customizable User Interface — RGB–color, tactile feedback, backlit buttons with custom labeled, removable button caps, allowing simple and intuitive end–user and guest control over facility deployed devices and systems.
- Flexible Room Control — Control any room device via LAN connections, multiple RS–232 and RS–485 serial ports, and various IR, relay and general purpose I/O built–in device ports. Connect the keypad to an IP network with additional control gateways interfacing with remote controlled devices, for extending control across large space facilities.
- Expandable Control System — According to arising demands, easily expands to be part of a larger control system, or coupled–operation with auxiliary keypads, via either LAN or K–NET™ single cable connection delivering both power and communication.
- Simple Control Programming — Using K–Config software. Leverage the power of Kramer’s highly customizable, flexible and user–friendly software, to easily program complex control scenarios of Pro–AV, Lighting, and other room and facility controlled devices.
- Easy and Cost–effective Installation — Compactly fits into standard US, EU and UK 1–gang in–wall box size, allows decorative integration with room deployed user interfaces such as electrical switches. Keypad installation is fast and cost–effective via a single LAN cable providing both power (PoE) and communication connections.
RC−206 is a compact 6−button control keypad that fits US 1−gang wall junction boxes. It fits decoratively within a room design. It is perfectly suited for use as a user interface keypad within a Kramer Control system. Using K−Config, tap into the rich, built−in I/O interfaces that enable this keypad to be used as a flexible, standalone room controller. In this way, it is ideal for classroom and meeting room control, providing end−user convenient control of complex multimedia systems and other room facilities such as screens, lighting and shades.
Multiple keypads can be linked together side−by−side or at a distance, via a single K–NET™ cable carrying both power and communication, providing uniform design and user experience.
- Clear and Customizable User Interface — RGB–color, tactile feedback, backlit buttons with custom labeled, removable button caps, allowing simple and intuitive end–user and guest control over facility deployed devices and systems.
- Flexible Room Control — Control any room device via LAN connections, multiple RS–232 and RS–485 serial ports, and various IR, relay and general purpose I/O built–in device ports. Connect the keypad to an IP network with additional control gateways interfacing with remote controlled devices, for extending control across large space facilities.
- Expandable Control System — According to arising demands, easily expands to be part of a larger control system, or coupled–operation with auxiliary keypads, via either LAN or K–NET™ single cable connection delivering both power and communication.
- Simple Control Programming — Using K–Config software. Leverage the power of Kramer’s highly customizable, flexible and user–friendly software, to easily program complex control scenarios of Pro–AV, Lighting, and other room and facility controlled devices.
- Easy and Cost–effective Installation — Compactly fits into standard US, EU and UK 1–gang in–wall box size, allows decorative integration with room deployed user interfaces such as electrical switches. Keypad installation is fast and cost–effective via a single LAN cable providing both power (PoE) and communication connections.
RC−306 is a compact 6−button control keypad that fits US, European and UK standard 1−gang wall junction boxes. Easy to deploy with a single LAN cable carrying both power (PoE) and communication, it fits decoratively within a room design. It is perfectly suited for use as a user interface keypad within a Kramer Control system. Using K−Config, tap into the rich, built−in I/O interfaces that enable this keypad to be used as a flexible, standalone room controller. In this way, it is ideal for classroom and meeting room control, providing end−user convenient control of complex multimedia systems and other room facilities such as screens, lighting and shades.
Multiple keypads can be linked together side−by−side or at a distance, via a single K–NET™ cable carrying both power and communication, providing uniform design and user experience.
- Clear and Customizable User Interface — RGB–color, tactile feedback, backlit buttons with custom labeled, removable button caps, allowing simple and intuitive end–user and guest control over facility deployed devices and systems.
- Flexible Room Control — Control any room device via LAN connections, multiple RS–232 and RS–485 serial ports, and various IR, relay and general purpose I/O built–in device ports. Connect the keypad to an IP network with additional control gateways interfacing with remote controlled devices, for extending control across large space facilities.
- Expandable Control System — According to arising demands, easily expands to be part of a larger control system, or coupled–operation with auxiliary keypads, via either LAN or K–NET™ single cable connection delivering both power and communication.
- Simple Control Programming — Using K–Config software. Leverage the power of Kramer’s highly customizable, flexible and user–friendly software, to easily program complex control scenarios of Pro–AV, Lighting, and other room and facility controlled devices.
- Easy and Cost–effective Installation — Compactly fits into standard US, EU and UK 1–gang in–wall box size, allows decorative integration with room deployed user interfaces such as electrical switches. Keypad installation is fast and cost–effective via a single LAN cable providing both power (PoE) and communication connections.
C−USBC/DPM is a high quality USB type−C (M) to DisplayPort (M) 6ft cable, that enables DisplayPort equipped monitors, TVs and projectors to be connected to any USB−C port that supports DP Alt Mode (DisplayPort Alternate Mode). This cable supports up to 4K@60Hz (4:4:4) resolution and delivers a direct connection that eliminates excess adapters and cabling, ensuring a tidy, professional installation.
- Max. Resolution — 4K@60Hz (4:4:4).
- HDCP 2.2 Support.
- Enables connecting a DisplayPort equipped monitor or projector to a USB–C port using a single cable.
- No special driver installation or additional power source is required.
- Regulatory Standards — CE, FCC and RoHS.
Kramer's C−USB3/AB is a SuperSpeed USB 3.0 Type−A male to Type−B male cable used to connect computers and peripherals, such as printers, scanners, cameras, keyboards, mice and other digital devices for superior signal transfer of up to 4.8Gbps.
- USB 3.0 A Male to B Male.
- Transfer Rates up to 4.8Gbps — 10x the capability of USB 2.0.
- Foil & Overall Braid Provide Maximum Protection Against EMI/RFI.
- Molded Strain Relief.
- Backward Compatibility — USB Specifications 1.0, 1.1 and 2.0.
- RoHS Compliant.
- Varied Selection of Lengths — Available in versions of 3 to 6ft (0.9 to 1.8m).
Kramer's C−USB3/MicroB is a SuperSpeed USB 3.0 Type−A male to MicroB male cable used to connect computers and peripherals such as, external hard drives and other digital devices for superior signal transfer of up to 4.8Gbps.
- USB 3.0 A (Male) to Micro–B (Male).
- Transfer Rates up to 4.8Gbps — 10x the capability of USB 2.0.
- Foil & Overall Braid Provide Maximum Protection Against EMI/RFI.
- Molded Strain Relief.
- Backward Compatibility — USB Specifications 1.0, 1.1 and 2.0.
Kramer's C−USB/C cables connect USB−C enabled devices with standard USB−A, B and Micro B devices (laptops, hard drives, legacy printers, hubs, smartphones, tablets and cameras). C−USB/C cables offer a whole new level of connectivity to devices using the new USB Type−C connector.The symmetrical, low profile USB Type−C connector can be plugged in any direction, eliminating the frustration of getting the port insertion just right.
- Quality Construction — High–quality shielded twisted pair (STP) construction, helps to prevent electromagnetic interference and ensures reliable data communication.
- Reversible USB Type–C Connector.
- Max. Data Rate — 480Mbps.
- Current Rating — 3A and 5A.
- PC, Mac & Mobile Compatible.
- Plug and Play — For printers, scanners, keyboards and other digital devices.
- Backward Compatibility — USB specifications 1.0 and 1.1.
- Molded Strain Relief — On the USB A, B & Micro B ends.
Kramer's C−USB/C cables connect USB−C enabled devices with standard USB−A, B and Micro B devices (laptops, hard drives, legacy printers, hubs, smartphones, tablets and cameras). C−USB/C cables offer a whole new level of connectivity to devices using the new USB Type−C connector.The symmetrical, low profile USB Type−C connector can be plugged in any direction, eliminating the frustration of getting the port insertion just right.
- Quality Construction — High–quality shielded twisted pair (STP) construction, helps to prevent electromagnetic interference and ensures reliable data communication.
- Reversible USB Type–C Connector.
- Max. Data Rate — 480Mbps.
- Current Rating — 3A and 5A.
- PC, Mac & Mobile Compatible.
- Plug and Play — For printers, scanners, keyboards and other digital devices.
- Backward Compatibility — USB specifications 1.0 and 1.1.
- Molded Strain Relief — On the USB A, B & Micro B ends.
Kramer’s C−UA/LTN cable is a MFi certified USB 2.0 cable to connect and charge your iPhone®, iPad® or iPod® with a Lightning™ connector.The cable can be used to connect to your computer's USB port for syncing and charging or to a USB power adapter for reliable charging from a wall outlet. The Lightning connector fits in either direction to enable easier connection of your Apple devices.
- Quality Performance — For reliable syncing and charging, Kramer’s C–UA/LTN cable is built using high–quality materials with durable construction for maximum flexibility.
- Compatible Devices — iPhone 6, 6 Plus, 5, 5C and 5S; the iPod Nano, the iPod Touch, the iPad Mini, the iPad Air and the 4th generation iPad.
- Available Colors — White & black.
- MFi Certified.
Due to its design, USB cable has a normal maximum length of about 5 meters (16.4 feet), but you can get longer distances by using the CA−UAM/UAF active USB extension cable from Kramer!
This is a bus−powered extension cable that can be used to increase the length of a device without any signal loss or potential performance problems. It contains active electronics, which boost the USB signal for maximum reliability and performance over extended distances. The cable operates as a self−powered extender, for use with USB cameras‚ printers‚ webcams‚ keyboard/mouse, etc.
- True Plug–and–Play — No additional drivers needed.
- USB 2.0 High Speed (480Mbps) Standard.
- Construction — 1 pair 24AWG + 2 pair 22AWG + drain wire 24AWG, tinned copper braid.
- No External Power — Pulls power from source.
- Data Transfer Only — Not for charging.
- Buffers Incoming & Outgoing Signal.
- Compliant with USB 2.0.
- CM–c(ETL) Rated.
Kramer's C−USB/C cables connect USB−C enabled devices with standard USB−A, B and Micro B devices (laptops, hard drives, legacy printers, hubs, smartphones, tablets and cameras). C−USB/C cables offer a whole new level of connectivity to devices using the new USB Type−C connector.
The symmetrical, low profile USB Type−C connector can be plugged in any direction, eliminating the frustration of getting the port insertion just right.
This model features a male USB–C connector on both ends of the cable.
- Quality Construction — High–quality shielded twisted pair (STP) construction, helps to prevent electromagnetic interference and ensures reliable data communication.
- Reversible USB Type–C Connector.
- Max. Data Rate — 480Mbps.
- Current Rating — 3A and 5A.
- PC, Mac & Mobile Compatible.
- Plug and Play — For printers, scanners, keyboards and other digital devices .
- Backward Compatibility — USB specifications 1.0 and 1.1.
- RoHS Compliant.
Kramer's C−USB3/AAE is a SuperSpeed USB 3.0 Type−A male to Type−A female extension cable used to connect computers and peripherals such as, printers, scanners, cameras, keyboards, mice and other digital devices for superior signal transfer of up to 4.8Gbps.
- USB 3.0 A Male to A Female.
- Transfer Rates up to 4.8Gbps — 10x the capability of USB 2.0.
- Foil & Overall Braid Provide Maximum Protection Against EMI/RFI.
- Molded Strain Relief.
- Backward Compatibility — USB Specifications 1.0, 1.1 and 2.0.
C−USBC/HM is a high quality USB type−C (M) to HDMI (M) 6ft cable, that enables HDMI equipped monitors, TVs and projectors to be connected to any USB−C port that supports DP Alt Mode (DisplayPort Alternate Mode).
This cable support up to 4K@60Hz (4:4:4) resolution and delivers a direct connection that eliminates excess adapters and cabling, ensuring a tidy, professional installation.
- Max. Resolution — 4K@60Hz (4:4:4).
- HDCP 2.2 Support.
- Enables connecting an HDMI equipped monitor or projector to a USB–C port using a single cable.
- No special driver installation or additional power source is required.
- Regulatory Standards — CE, FCC and RoHS.
KDock−1 is a USB−C hub multiport adapter specially designed to support mobile devices and is an ideal accessory for MacBook, laptops equipped with USB type−C, smartphones, and tablets. KDock−1 enables you to connect your USB−C device to an HDMI™ video output, USB 3.0 port, and USB−C charging pass−through.
Note: Video output for smartphones is supported only for smartphones that support DisplayPort Alt mode through USB−C.
KDock−3 is a USB−C hub multiport adapter specially designed to support mobile devices and is an ideal accessory for MacBook, laptops equipped with USB Type−C, mobile phones, and tablets. KDock−3 enables you to connect your USB−C device to HDMI™ and DisplayPort video outputs, 2 USB 3.0 ports, an Ethernet port, SD card port and USB−C data and charging pass−through.
Note: Video output for smartphones is supported only for smartphones that support DisplayPort Alt mode through USB−C.
KDock−2 is a USB−C hub multiport adapter specially designed to support mobile devices and is an ideal accessory for MacBook, laptops equipped with USB Type−C, smartphones, and tablets. KDock−2 enables you to connect your USB−C device to an HDMI™ video output, 2 USB 3.0 ports, an Ethernet port, SD card port and USB−C port for data transmission and charging.
Note: Video output for smartphones is supported only for smartphones that support DisplayPort Alt mode through USB−C.
Description
C−U32/FF is a USB−C(M) to USB−C(M), USB 3.2 Gen−2 SuperSpeed cable offering a whole new level of reliable connectivity thanks to kramer's unique K−lock. Transfer Video 4K@60 data at incredible speeds (10G), charge other devices (100W), and even power mobile devices − all with just one Active cable.
C−U32/FF offers throughput of up to 10Gbps when used with a USB 3.2 host and device. The symmetrical, low profile USB Type−C connector, with the integrated K−Lock mechanism, can be plugged in any direction, thus eliminating the frustration of getting the port insertion just right.
Features
- Quality Construction — High–quality shielded twisted pair (STP) construction helps prevent electromagnetic interference and ensures reliable data communication.
- Reversible USB Type–C Connector with integrated locking mechanism.
- Transfer Rates — Up to 10Gbps.
- 100W power (5A, 20V).
- PC, Mac & Mobile Compatible.
- Plug and Play — For monitors, Web cameras, printers, scanners, keyboards and other digital devices.
- USB Backward Compatibility — 1.0, 1.1, 2.0 and 3.0.
- Logo on mold as orientation mark
Description
TP−580Rxr is a high−performance, extended−reach HDBaseT receiver for 4K@60Hz (4:2:0) HDMI, RS−232 and IR signals over twisted pair. It extends video signals to up to 100m (330ft) over CAT copper cables at up to 4K@60Hz (4:2:0) 24bpp video resolution and provides even further reach for lower HD video resolutions.
Highlights
- HDBaseT 1.0 receiver
- Up to 180m (590ft) at 1080p
- Up to 100m (330ft) at 4K@60Hz (4:2:0)
- Up to 4K@60Hz (4:2:0) 24bpp video resolution
- Control extension
Features
- High Performance Standard Extender — Professional HDBaseT extender for providing extended–reach signals over twisted–pair copper infrastructures. TP–580Rxr is a standard extender that can be connected to any market–available HDBaseT–compliant extension product. For optimum extension reach and performance, use recommended Kramer cables.
- HDMI Signal Extension — HDCP 2.2 compliant. Supports deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0. EDID and CEC signals are passed through from the source to the display.
- I–EDIDPro™ Kramer Intelligent EDID Processing™ — Intelligent EDID handling, processing and pass–through algorithm that ensures Plug and Play operation for HDMI source and display systems.
- Multi–channel Audio Extension — Up to 32 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
- Bidirectional RS–232 Extension — Serial interface data flows in both directions, allowing data transmission device control.
- Bidirectional Infrared Extension — IR interface data flows in both directions, allowing remote control of peripheral devices located at either end of the extended line.
- Cost–effective Maintenance — Status LED indicators for HDMI and HDBT ports facilitate easy local maintenance and troubleshooting. Local firmware upgrade via RS–232 connection and the K–Upload tool ensures lasting, field–proven deployment.
- Easy Installation — Compact DigiTOOLS® fan–less enclosure for dropped–ceiling mounting, or side–by–side mounting of 3 units in a 1U rack space with the recommended rack adapter
Applications
- Long–distance AV signal extension for multi–room, large dividable auditoriums and lecture hall connectivity
- AV extension in conference rooms, boardrooms, control rooms, hotels and large church facilities
RK−T2SB−B is a 19−inch rack adapter for mounting 1 Kramer MegaTOOLS™ size device and 1 Kramer TOOLS™ size device into a 1U rack space.
RK−3T−B is a 19−inch rack adapter for mounting 3 Kramer TOOLS™ size devices in a 1U rack space.
Description
VP−778 is a presentation matrix switcher/scaler that can be configured as a single 4K output (4K@30Hz UHD [3840x2160]) or dual HD scaler with full PiP capabilities. It can scale to two independent HDMI outputs, each with a parallel HDBaseT output. VP−778 includes both analog and embedded audio inputs and outputs and audio DSP features. It also features two microphone inputs and digital & analog balanced stereo and amplified speaker outputs. VP−778 can be controlled using built−in web pages, RS−232 and IR.
Highlights
- Dual independent scalers with seamless switching
- HDBaseT inputs and outputs
- Max. single output resolution 4K30 UHD (3840x2160)
- K–IIT XL™ PIP
- 2 microphone inputs, stereo speaker output
- Luma & chroma keying
- Two programmable user buttons
- Control options: IR RS–232, Ethernet with Web browser, front panel and OSD
- 4 HDMI Inputs, 2 HDBaseT inputs and 2 DVI–U connectors with configurable input type — HDMI, VGA, Component or Composite Video
Features
- Pix Perfect™ Scaling — State–of–the–art Kramer technology.
- K–IIT XL™ Picture–in–Picture Image Insertion Technology — Ultra–stable picture–in–picture, picture–and–picture and split–screen.
- Seamless Video Switching — Swap or follow (transition type) and cut or fade (transition effect).
- Dual Scalers — “Live” seamless transitions with two independent outputs.
- 8 Input Buttons per Channel.
- Main and PiP Window Customization — In overlay mode.
- Projection Setups — Front, back, ceiling front and ceiling back.
- Output Resolutions — Up to 4K@30Hz UHD (3840x2160) in single–window mode, HDTV and computer graphics resolutions with selectable refresh rates.
- Inputs — Choice of HDMI, VGA, YUV, or CV on two DVI–U inputs, 4 HDMI and 2 HDBaseT inputs.
- Two Programmable User Buttons — For passing serial commands.
- Serial Comms Matrix — Up to eight sets of configurable unidirectional connections for passing serial data from source to destination.
- HDBaseT™ Technology — Max. data rate of 6.75Gbps (2.25Gbps per graphic channel).
- System Range (HDBaseT™) — Up to 130m (430ft) in normal mode; up to 180m (590ft) in ultra–mode (1080p @60Hz @24bpp) when using BC–UNIKAT cables.
- Cables — For optimum range and performance, use the recommended Kramer cables available at www.kramerav.com/product/VP–778.
- Audio — Balanced stereo audio inputs, two microphone inputs, digital stereo and balanced stereo outputs, input/output audio level adjustment, and audio DSP.
- Built–in 2x10W Power Amplifier — Speaker outputs on a 4–pin terminal block connector.
- Microphone — Talkover or mix modes.
- Auto Switching — Automatically scans inputs based on a predefined priority and selects first live input found or last connected.
- Audio–Follow–Video (AFV) & Breakaway.
- Advanced De–interlacing — 3D comb filtering, film mode, diagonal correction, and motion detection.
- Multiple Aspect Ratio Selections.
- Built–in Proc–Amp — With enhanced functions such as color correction, gamma, dither, and noise reduction.
- Power Management Modes — Save energy and money.
- HDCP Compliance.
- Luma — and Chroma–Keying.
- Advanced EDID Management — Native resolution and color depth modeline per input.
- Built–in Test Patterns — For screen setup and alignment.
- Output EDID Analysis — For optimal scaling.
- Input & Output Color Space Control.
- HDMI Deep Color.
- On–Screen Display (OSD) — Provides easy setup and adjustment.
- Non–Volatile Memory — Retains settings.
- Firmware Upgrade Input — Via USB memory stick.
- Various Control Options — Front panel buttons, Ethernet web page, RS–485, IR, RS–232 serial commands transmitted by a touch screen system, PC, or other serial controller.
Applications
- Projection systems in conference rooms, boardrooms, auditoriums, hotels and churches, production studios, rental and staging
- Any application where high quality switching and/or scaling of multiple and different video signals is required for projection purposes
Description
WP-20 is a high−performance, 4K, multi−format, wall−plate switcher and transmitter over extended−reach HDBaseT. Offering intelligent Maestro automation, with priority and last−connected switching options, it automatically switches and operates the room according to the selected switching scheme based on active video signal detection.
Key Features
- Simple and Powerful Maestro Room Automation — Intuitive user interface enables you to fully automate your meeting room elements. Configure lights, shades, devices and more to be activated by an extensive range of triggers, including input/output connectivity, routing, and button pressing. By minimizing user intervention, Maestro room automation saves meeting prep time and minimizes human error before presentations.
- High Performance Switcher Transmitter — Professional HDBaseT Switcher transmitter for providing extended–reach signals over twisted pair copper infrastructures. This switcher transmitter is a standard transmitter that can be connected to any market–available HDBaseT–compliant extension product.
- BYOD Plug & Play Auto Switcher — Automatically plays the switched user device source signal on the connected display according to user–configured preferences, such as priority or last–connected input. When the user manually switches, by pressing a button, the auto switching is overridden.
- Simple Switching Operation — Local buttons or remotely connected contact–closure buttons for flexible user input selection and switching control.
- HDMI™ Signal Switching — HDCP compliant, supporting deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0.
- I–EDIDPro™ Kramer Intelligent EDID Processing™ — Intelligent EDID handling, processing, locking and pass–through algorithm ensures plug & play operation for HDMI source and display systems.
- Multi–channel Audio Switching — Up to 32 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
- Audio Embedding — An auto–detected analog stereo audio input, per user selection, is converted into a digital signal and embedded in the output HDMI signal, replacing the source HDMI audio input signal. This enables, for example, a presenter to temporarily override the playing source audio with speech description.
- Audio De–embedding — The digital audio signal passing–through to the output, is de–embedded, converted to an analog signal and sent to the stereo analog audio output. This enables playing the audio on locally connected speakers, in parallel to playing it on the speakers connected to the AV acceptor device (such as TVs with speakers).
- Ethernet Extension — Ethernet interface data flows in both directions, allowing extension of up to 100Mbps Ethernet connectivity for LAN communication and device control.
- Bidirectional RS–232 Extension — Serial interface data flows in both directions, allowing data transmission and device control.
- Reliable PoE (Power over Ethernet) Powering — Auto–senses the extension line PoE status, it accepts power from a remote PoE provider such as a PoE matrix, with optional mains powering from connected power adapter.
- Cost–effective Maintenance — Status LED indicators for HDMI, VGA and HDBT ports facilitate easy local maintenance and troubleshooting. Remote IP–driven device management via built–in web pages and RS–232 connection. Local and remote firmware upgrade via RS–232 or Ethernet connection tool ensure lasting, field–proven deployment.
- Easy Installation — Compactly fits into standard US, EU and UK 2–gang in–wall box size, supporting decorative integration with room deployed user interfaces such as electrical switches. Wall–plate installation is fast and cost–effective via a single twisted pair cable, providing both video signal and power (PoE) connections.
Applications
- Podium–mounted switcher in lecture halls, training rooms, auditoriums and hospitality applications.
- Wall–mounted switcher within any AV distribution system.
- Multimedia and presentation source selection in various corporate applications.
Description
WP 20CT is is an intelligent 2x1 automatic wall−plate switcher transmitter over long−reach HDBaseT for 4K USB−C and HDMI video signals. WP 20CT offers an intelligent switching experience with built−in Maestro room control and the standard priority / last−connected switching function based on active video signal detection.
Key Features
- High Performance Switcher Transmitter — Professional HDBaseT Switcher transmitter for providing long–reach signals over twisted pair copper infrastructures. This switcher transmitter is a standard transmitter that can be connected to any market–available HDBaseT–compliant extension product.
- Simple and Powerful Maestro Room Control — Out–of–the–box configured room control for a typical meeting room setup, and intuitive user interface enables you to control your meeting room elements. Room devices are controlled, locally or remotely via HDBaseT, right out–of–the–box by an extensive range of triggers, including input/output connectivity and routing. By minimizing user intervention, Maestro room control saves meeting prep time and minimizes human error before presentations.
- Automatic Display Operation — Part of the out–of–the–box Maestro configured room automation. Meeting presentation is simplified by automatically turning ON/OFF a CEC–enabled display when the presentation source is plugged in / unplugged with user–defined shut–down delay.
- BYOD Ease and Convenience — Connect any DP–Alt–Mode–capable USB–C device as an AV presentation source, while providing the connected device, if PD–2.0–capable, with up to 60 watts of power (with the use of an optional 20V power supply).
- Plug & Play Auto Switcher — Automatically plays the switched user device source signal on the connected display according to user–configured preferences, such as priority or last–connected input. When the user manually switches, by pressing a button, the auto switching is overridden.
- HDMI™ Signal Switching — HDCP 2.3 compliant, supporting deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0.
- Multi–channel Audio Switching — Up to 8 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
- Audio De–embedding — The digital audio signal passing–through to the output, is de–embedded, converted to an analog signal and sent to the stereo analog audio output. This enables playing the audio on locally connected speakers, in parallel to playing it on the speakers connected to the AV acceptor device (such as TVs with speakers).
- Bidirectional RS–232 Extension — Serial interface data flows in both directions, allowing data transmission and device control.
- Reliable PoE (Power over Ethernet) Powering — Auto–senses the HDBaseT extension line PoE status, it accepts power from a remote PoE provider such as a PoE matrix, with optional mains powering from connected power adapter.
- Cost–effective Maintenance and Management — Status LED indicators for Power, HDMI, and HDBT ports facilitate easy local maintenance and troubleshooting. Local device management using built–in web interface via the USB–C connection . Local firmware upgrade via USB–C and RS–232 connection tool ensure lasting, field–proven deployment.
- Easy Installation — Compactly fits into standard 1–gang in–wall box size, supporting decorative integration with room deployed user interfaces such as electrical switches. Wall–plate installation is fast and cost–effective via a single twisted pair cable, providing both video signal and power (PoC) connections.
Applications
The WP−580T is a high−performance, HDBaseT twisted pair wall plate transmitter for 4K@60Hz (4:2:0) HDMI signals. The WP−580T inputs the signals and converts them into an HDBaseT twisted pair signal that it transmits to a WP−580R receiver. The WP–580T(D) model is supplied with a Midway Size 2 gang DECORA® design frame.
- Max. Data Rate — 10.2Gbps (3.4Gbps per graphic channel).
- HDTV Compatible.
- HDCP 2.2 Compliance.
- HDBaseT™ Technology.
- HDMI Support — Deep Color, x.v.Color™, Lip Sync, HDMI Uncompressed Audio Channels, Dolby TrueHD, DTS–HD, CEC.
- 3D Pass–Through.
- EDID PassThru — Passes EDID signals between the source and display.
- 2K & 4K Support.
- System Range — Up to 70m (230ft).
- Cable — For optimum range and performance using HDBaseT™, use Kramer's BC–HDKat6a cable. Note that the transmission range depends on the signal resolution, source and display used. The distance using non–Kramer CAT 6 cable may not reach these ranges.
- Indicators — Status LEDs for input, output, link and power.
Description
WP−211T is a high−performance PoE−powered wall−plate automatic switcher of 4K HDMI video signals, transmitted over long−reach HDBaseT extension link. Offering priority and last−connected switching options, it automatically switches according to the selected switching scheme based on active video signal detection.
Key Features
- Plug & Play Auto Switcher — Wall or podium mountable switcher, easily accessible for plugging user device to any of its HDMI input connections, it auto–plays switched source signal on connected display according to user–configured preferences.
- Automatic Input Selection — Plug & play auto switching based on last connected input or manual selection.
- High Performance Switcher Transmitter — Professional HDBaseT Switcher transmitter for providing long–reach signals over twisted pair copper infrastructures. This switcher transmitter is a standard transmitter that can be connected to any market–available HDBaseT–compliant extension product.
- HDMI Signal Switching — HDMI 2.0 and HDCP 2.2 compliant, it supports deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D.
- Multi–channel Audio Switching — Up to 32 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
- I–EDIDPro™ Kramer Intelligent EDID Processing™ — Intelligent EDID handling, processing, locking and pass–through algorithm ensures Plug and Play operation for HDMI source and display systems.
- Reliable PoE (Power over Ethernet) Powering — Auto–senses the extension line PoE status, it accepts power from a remote PoE provider such as a PoE matrix, with optional mains powering from connected power adapter.
- Easy Installation — Compactly fits into standard US, EU and UK 1–gang in–wall box size, supporting decorative integration with room deployed user interfaces such as electrical switches. Wall–plate installation is fast and cost–effective via a single twisted pair cable, providing both video signal and power (PoE) connections.
Description
WP−789R is a high−performance, long−reach HDBaseT wall−plate receiver for 4K@60Hz (4:2:0) HDMI and HDCP 2.2 signals over twisted pair. It converts the transmitted HDBaseT signal into an HDMI signal. It extends video signals up to 40m (130ft) over Kramer copper cables at 4K@60Hz (4:2:0) 24bpp video resolution and provides even further reach for lower HD video resolutions. This wall−plate is powered through PoE (Power over Ethernet) over the twisted pair cable.
Key Features
- High Performance Receiver — Professional HDBaseT receiver for providing long–reach signals over twisted pair copper infrastructures. WP–789R is a standard extender that can be connected to any market–available HDBaseT–compliant extension product. For optimum extension reach and performance, use recommended Kramer cables.
- Reliable PoE (Power over Ethernet) Powering — Auto–senses the extension line PoE status, and accepts power from a remote PoE provider such as a PoE matrix, with optional mains powering from connected power adapter.
- HDMI Signal Extension — Supports HDCP 2.2, deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0.
- EDID Pass–through — Pass–through algorithm ensures Plug and Play operation for HDMI source and display systems.
- Multi–channel Audio Extension — Up to 32 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
- Low Profile Wall–Plate — Designed for elegant, in–wall deployment behind a wall–mounted flat panel display. Minimizes the depth of the installation, especially when connected with a Kramer right–angle HDMI cable.
- Cost–Effective Maintenance — Power and connectivity status LED indicator facilitates easy local maintenance and troubleshooting.
- Easy Installation — Fits into standard US, EU and UK 2–gang in–wall box size, supporting decorative integration with room deployed user interfaces such as electrical switches. Wall–plate installation is fast and cost–effective via a single twisted pair cable, providing both video signal and power (PoE) connections.
Applications
- Decorative wall–mounted display installations in visitor centers, museums, auditoriums and boardrooms
- Cruise ships and yachts with low–profile display installations on lean walls
- Any display deployments with limited space for receiver installation
Description
WP−3H2 is a 4K HDR HDMI wall−plate extender that extends the HDMI cable distance between the HDMI player and the HDMI display by reclocking and equalizing the HDMI signal. Placing WP−3H2 in the transmission path, removes dropout and digital noise (sparkles) in your picture that may result from using long HDMI cables.
Key Features
- Extends HDMI Transmission Distance — Extends 4K@60Hz (4:4:4) signals up to 20m from the source (10m from the source to the HDMI Extender, and 10m from the HDMI extender to the display).
- Supports the DDWG standard for HDMI compliant displays.
- HDMI Support — Supports HDR10, ARC, CEC, deep color, x.v.Color™, Lip Sync, 7.1 PCM, Dolby TrueHD, Dolby atmos DTS–HD, 2K, 4K, and 3D Dolby Vision as specified in HDMI 2.0.
Supports the DDWG standard for HDMI compliant displays. - Kramer reKlocking™ & Equalization Technology — Rebuilds the digital signal to travel longer distances.
- Content Protection — HDCP 1.4 and HDCP 2.2 compliant.
Applications
- Pro AV multimedia
- Home cinema
Description
WP−EN6 is a 2−gang (US) wall−plate video encoder that provides streaming of 4K@60Hz (4:2:0), HDCP 2.2, HDMI video, IR, RS−232, and USB signals over an IP network in unicast (one−to−one) or multicast (many−to−many) configurations.
Key Features
- High Resolution Video Streaming — 4K@60Hz (4:2:0) HDMI with HDCP 2.2 compliance.
- Maximum Compatibility — Fully standard and compliant JPEG 2000 codec, enables compatibility with other software and hardware encoders. Open encoding enables software decoding through VLC™ player software.
- Reliable PoE (Power over Ethernet) Powering — Auto–senses the extension line PoE status, and accepts power from a remote PoE provider such as a PoE matrix, with optional mains powering from connected power adapter (not included).
- Standard Ethernet Network Operation — 10M/100M/1000M.
- Selectable Streaming Mode — Unicast or multicast through RTSP (Real Time Streaming Protocol).
- Flexible Video Wall Setups — 1 to 256 screens.
- Virtualization — IR, USB, RS–232 over IP.
- Network — Switch 1G multicast IGMP snooping managed layer 2.
- Easy Installation — Fits into standard US 2–gang in–wall box size, supporting decorative integration with room deployed user interfaces such as electrical switches. Wall–plate installation is fast and cost–effective via a single twisted pair cable, providing both video signal and power (PoE) connections.
Applications
- Sports Bars
- Schools and Universities
- Corporate offices
- Government
- Airports and other public venues with AV distribution systems of one or more sources and many displays
- Long–distance transmission of signals using existing wires and infrastructure
KT−205WM is a new powerful, 5.5 inch, IPS, multi−touch, touch panel with 720x1080 (10:16) resolution. Elegantly designed for wall−mounted decorative room integration. KT−205WM runs the latest Android 11, supports wired PoE (Power over Ethernet) and advanced Wi−Fi connectivity options. The touch panel has a built−in speaker and microphone and comes with a wall mount. The touch panel is easy to assemble, with elegant wiring and secured mounting providing reliable operation and flexible deployment. KT−205WM touch panel is ideal for 24/7 Kramer−supported commercial AV or control applications and features a user−friendly, fully customizable graphical user interface configured by Kramer software.
VS−211X is a high−performance 2x1 automatic switcher for 4K HDR, HDMI video signals. Offering priority and last−connected switching options, it automatically switches according to the selected switching scheme based on active video signal detection.
CP−AOCH/60F is an innovative active optical HDMI cable for 4K signals up to 90 meters (295ft).
CP−AOCH/60F cables are thinner, lighter, and more flexible than copper or even standard optical cables. They offer transparent EDID and HDCP support with no signal attenuation and reduced risk of EMI and RFI interference. CP−AOCH/60F cables are an ideal solution for maximizing signal integrity in critical AV installations.
- Video Resolution — Up to 4K@60Hz (4:4:4).
- High Data Transfer Rate — Up to 18Gbps.
- Embedded Audio — PCM 8–channel, Dolby Digital True HD and DTS–HD Master Audio.
- HDMI Support — HDCP 2.2/1.4, HDR, EDID, ARC and CEC.
- High–Quality Connectors — 24K gold–plated, corrosion–resistant and best possible connectivity.
- Reduced EMI & RFI.
- Thin Construction — 4.5mm diameter.
- Jacket Construction — Plenum rated.
- RoHS 2011/65/EU CE,FCC Compliant.
- Varied Selection of Lengths — Available in versions from 10 to 90m (33 to 295ft).
HDMI Passive Wall Plate
- Front Panel Connection — 1 HDMI (F).
- Rear Panel Connection — 1 HDMI (F) on a flat, flexible cable.
- Dimensions — 2.71" x 1.57" x 4.49" W, D, H.
FC−404NETxl is a hybrid, analog and Dante, audio cross−connect mixer. Input audio, either analog lines/microphones or Dante audio over IP channels, are mixed and cross−connected to the analog audio output lines and/or Dante audio over IP output streams. The mixer accepts PoE via its network connection.
- High Performance Standard Mixer — Professional mixer, mixing any audio inputs to any outputs, including auto analog to digital audio format conversion, flexible input or cross–connect level and output gain adjustment. As a standard–compliant mixer, it connects to any market–available AES67–compliant Dante product.
- Hi–quality Sound Mixer — Features a fully flexible and preset signal management. Mix, route, and distribute any inputs and outputs in any audio format via simple click and connect. Select and toggle through 10 presets in the device’s embedded web pages’, or use API commands for a simple setup change with Kramer’s recommended room controller and adjustable level control.
- Professional, Open, Studio Grade Signal Conversion Technology — Includes the latest generation 32–bit advanced Digital Analog Converter architecture to achieve excellent dynamic performance and improved tolerance to clock jitter. Supports AES67 standard for open IP communication and interop. In addition, FC–404NETxl maintains the quality of the original audio signal with selectable sampling rates.
- Flexible Audio Cross–Connection — Fully configurable inputs, the analog lines, dynamic or condenser microphones, and audio over IP Dante channels, are mixed, format–converted and distributed to any set of outputs, either analog lines or audio over IP Dante streams.
- Comprehensive Unit Control and Configuration Options — Remote IP–based, or local serial, control via user–friendly embedded web pages, Protocol 3000 API commands, touch screen, or other controllers. The device is managed by Kramer Network or Dante DDM management.
- Versatile Powering — Powered by PoE through the Dante port or by a mains power adapter.
- Cost–Effective Maintenance — LED indicators for audio signals and network connection status facilitate easy local maintenance and troubleshooting. Remote IP–driven device management and optional whole site management system via built in web pages and RS–232 connection. Local and remote firmware upgrade via RS–232 or Ethernet connection tool ensure lasting, field proven deployment.
- Easy Installation — Single cable connectivity for both Ethernet signal and power. Compact DemiTOOLS® fan–less enclosure for surface mounting or side–by–side mounting of two units in a 1U rack space with the recommended rack adapter.
Applications
- Enterprise boardrooms and advanced conference rooms
- Education lecture halls and auditoriums
- Governmental large facilities with advanced audio mixing apps
- Any application with hybrid analog and digital audio mixing and cross–connection needs
The Galil 8-C Closed-back Ceiling Speaker features a multi−tap power transformer for selecting 8Ω (bypassing the transformer) or 70V/100V power settings that are suitable for an array installation.
- Type — 2–way coaxial speaker.
- Woofer — 8” polypropylene cone.
- Tweeter — 1” silk dome.
- Impedance — 8Ω.
- Power Handling — 64W RMS, 180W continuous program.
- Transformer Taps — 70V: 64W/32W/16W/8W/4W/Off (Lo–Z); 100V: 64W/32W/16W/8W/Off (Lo–Z).
- UL 1480 & 2043 Listed
- Package Includes — 2 speakers (1 pair), ceiling mounting kit, template and user manual.
PA−240Net is a high−performance, selectable Hi−Z (70V/100V) or Lo−Z (4Ω/8Ω) power amplifier featuring balanced and unbalanced inputs and additional line−level output and Dante interface. This versatile amplifier features built−in DSP, auto−standby and maximum durability. PA−240Net is suitable for a vast range of AV installations.
- High–performance Amplifier — With built–in DSP and additional balanced stereo line–level output. PA–240Net features flat frequency response, unmatched sonic performance, excellent signal to noise ratio, and extraordinarily low distortion levels.
- Adaptable to Any AV Installation — Switch between Lo–Z and Hi–Z to accommodate any type of loudspeaker installation. Select 1 Channel of 240W into a 70V/100V line or 2 channels of 120W into 4Ω/8Ω.
- Easy, Scalable and Cost–Effective Dante Audio Networking — Dante makes networking any size audio installation easy by providing digital signal transmission over a local area network using standard Internet protocols. The unit is part of the expanding family of products that make up Kramer’s Dante ecosystem. These products are fully compatible and integrate into any Dante–enabled system.
- Interoperability — Supports AES67 and Dante allowing high–performance interoperability between IP–based audio networking systems.
- Individual Mix Per Output — Each output supports an independent input mix with master volume, 3–band parametric EQ, and selectable high–pass filter. Create one output mix and EQ settings suitable for the venue and another for recording or cascading more amplifiers, powered speakers or subwoofers according to any AV installation requirements.
- Professional, Studio Grade Signal Conversion Technology — Includes the latest generation 32–bit advanced Digital Analog Converter architecture to achieve excellent dynamic performance and improved tolerance to clock jitter. Maintains the quality of the original audio signal with selectable sampling rates up to 96 kHz.
- Durable and Reliable — PA–240Net is immune to failure. It includes layers of protection against over–current, DC voltage at the outputs, high frequency, and over–heating with intelligent, heat–sensitive fans for added protection.
- Flexible Control Options — Control locally via RS–232 serial commands or remotely, via embedded web pages over Ethernet.
- Power Efficient — This super–efficient amplifier includes auto–standby for power saving and cost reducing operation. No need to rely on default auto–standby settings. Adjust your noise floor threshold based on exactly when your amplifier needs to go into sleep mode and when it needs to wake up.
- Easy Installation — ½ 19” size enables mounting in a 1U rack space with the recommended rack adapter.
PA−120Net is a high−performance, selectable Hi−Z (70V/100V) or Lo−Z (4Ω/8Ω) power amplifier featuring balanced and unbalanced inputs, additional line−level output and Dante interface. This versatile amplifier features built−in DSP, auto−standby and maximum durability. PA−120Net is suitable for a vast range of AV installations.
- High–performance Amplifier — With built–in DSP and additional balanced stereo line–level output. PA–120Net features flat frequency response, unmatched sonic performance, excellent signal to noise ratio, and extraordinarily low distortion levels.
- Adaptable to Any AV Installation — Switch between Lo–Z and Hi–Z to accommodate any type of loudspeaker installation. Select 1 Channel of 120W into a 70V/100V line or 2 channels of 60W into 4Ω/8Ω.
- Easy, Scalable and Cost–Effective Dante Audio Networking — Dante makes networking any size audio installation easy by providing digital signal transmission over a local area network using standard Internet protocols. The unit is part of the expanding family of products that make up Kramer’s Dante ecosystem. These products are fully compatible and integrate into any Dante–enabled system.
- Interoperability — Supports AES67 and Dante allowing high–performance interoperability between IP–based audio networking systems.
- Individual Mix Per Output — Each output supports an independent input mix with master volume, 3–band parametric EQ, and selectable high–pass filter. Create one output mix and EQ settings suitable for the venue and another for recording or cascading more amplifiers, powered speakers or subwoofers according to any AV installation requirements.
- Professional, Studio Grade Signal Conversion Technology — Includes the latest generation 32–bit advanced Digital Analog Converter architecture to achieve excellent dynamic performance and improved tolerance to clock jitter. Maintains the quality of the original audio signal with selectable sampling rates up to 96 kHz.
- Durable and Reliable — PA–120Net is immune to failure. It includes layers of protection against over–current, DC voltage at the outputs, high frequency, and over–heating with intelligent, heat–sensitive fans for added protection.
- Flexible Control Options — Control locally via RS–232 serial commands or remotely via embedded web pages over Ethernet.
- Power Efficient — This super–efficient amplifier includes auto–standby for power saving and cost reducing operation. No need to rely on default auto–standby settings. Adjust your noise floor threshold based on exactly when your amplifier needs to go into sleep mode and when it needs to wake up.
- Easy Installation — ½ 19” size enables mounting in a 1U rack space with the recommended rack adapter.
KDS−DEC7 decoder is an advanced receiver for streaming 4K video signals via Ethernet over copper cable. It decodes streams over an IP network to HDMI output, and transmit the USB, IR, RS−232, or CEC signal over IP network.
KDS−EN7 encoder is an advanced transmitter for streaming 4K video signals via Ethernet over copper cable. It encodes and streams over an IP network from HDMI input, and transmits the USB, IR, RS232, or CEC signal over IP network.
- For real–time essential installations such as command and control rooms
- For large scale AV content sharing installations using existing wires and infrastructure in corporate offices and government applications
- AV distribution systems with one or more sources and many displays in schools, universities, and public venues
- For AV installations where low latency KM/KVM capabilities are required
KDS−MP4 is a high−quality LAN−based 4K@60Hz (4:2:0) digital signage media player. The unit receives content from the Media Manager software installed on the PC, either via LAN or from an external USB memory stick, loads it into its internal memory and then displays it with image quality of up to 4K60 4:2:0 via the HDMI output.
- 4K@60Hz (4:2:0) Support.
- High Quality HDMI Video & Audio.
- Codec Format Support — MPEG–1, MPEG–2, MPEG L2, MP3, H.264/MPEG–4, and VC–1.
- Memory Options — 8GB internal.
- NTP Client — For time synchronization.
- Integrated SMIL Control — CMS device management in LAN environments.
- SMIL 3.0 Instruction (Sub–Set) Support.
- CMS Device Management — In LAN environments using the integrated SMIL control.
- Perforated Side Panel — For efficient heat dissipation.
- VESA Standard Mounting Bracket — For mounting on–wall, inside a cabinet or to the VESA standard screw holes on the rear panel of a display.
- Media Manager Software — For easy, powerful and versatile management of digital signage content via a PC.
- Media–Manager Multi–language Support — Ready–made templates for screen layouts, logos, tickers and widgets.
- Compact DigiTOOLS® — Built–in mounting bracket.
PS−504 is a desktop power supply (AC power cord included) with standard size DC output plug that provides 5V DC, 4A to any compatible device.
RK−T2B−B is a 19−inch rack adapter for mounting 2 Kramer MegaTOOLS™ size devices in a 1U rack space.
SL−240C is a compact master/space controller (Kramer Control brain) with PoE. It can operate over Ethernet with control interfaces that include: four bidirectional RS−232, four IR, four GPI/O, and four relays. It controls devices such as scalers, video displays, audio amplifiers, Blu−ray players, sensors, screens, shades, door locks, and lights. Multiple Kramer Ethernet control gateways can be used to add remote I/O ports.
- Space Controller — Controls any AV device/display with its corresponding logic.
- High Performance Architecture — Enables a scalable and flexible programming platform.
- 4 RS–232 Bidirectional Control Ports — For controlling devices via bi–directional serial control protocols.
- 4 IR Emitter & 1 IR Receiver Control Ports — Control devices via IR control protocols and learn commands from IR remotes.
- 4 GPI/O Control Ports — Control devices via general purpose I/O ports, program configured as digital input, digital output or analog input interface for controlling sensors, door locks, audio volume and lighting control devices.
- 4 Relay Control Ports — Control devices via relay contact closure, such as opening and closing drapes, shades, blinds, and projection screen scrolling.
- Resilient powering with PoE and optional PSU (not included).
- Network Support — 10/100/1000Mbps Ethernet.
- LED Indicators — I/O port state and system status.
- Software Management Support — Kramer Control, API.
KT−2015 is a new powerful, 15−inch, IPS, multi−touch, touch panel with 1920x1080 resolution. Elegantly designed for decorative room integration, this portable touch panel can be deployed either on a tabletop or wall. KT−2015, with the latest Android 11, supports wired PoE (Power over Ethernet) and advanced Wi−Fi connectivity options. The touch panel has a built−in speaker and camera and comes either with a tabletop or a wall mount. The touch panel is easy to assemble, using elegant wiring, secured mounting, reliable operation and flexible deployment. KT−2015 is a touch panel that is ideal for any 24/7 Kramer−supported commercial AV or control application and features a user−friendly, fully customizable graphical user interface configured by Kramer software.
