The VP−461 is a high−quality presentation switcher and scaler with PIP for computer graphics, HDMI and DisplayPort signals. It scales the video, embeds the audio and outputs the signal to the HDMI output, as well as to the computer graphics video output together with an unbalanced audio output.

• K–IIT XL™ Picture–in–Picture Image Insertion Technology — Ultra–stable picture–in–picture, picture–and–picture, and split screen capability. Any video source can be inserted into or positioned next to a DisplayPort video source or vice versa with window positioning and sizing controls.
• Kramer’s PixPerfect™ Scaling Technology — Kramer’s precision pixel mapping and high quality scaling technology. High–quality 3:2 and 2:2 pull down de–interlacing and full up and down–scaling of all video input signals.
• Ultra–Fast Fade–Thru–Black (FTB™) Switching — Video switching transitions are clean and ultra fast. The video fades to black and the new input fades from black for smooth, glitch–free switching. The output signal provides constant sync so the display never glitches.
• HDTV Compatible.
• 40 Output Resolutions — Up to WUXGA, 1080p and 2K.
• HDMI Deep Color Support.
• Luma Keying — Via PIP window.
• Vertical Keystoning.
• Built–in ProcAmp — Color, sharpness, contrast, brightness and gamma are set individually for each input.
• Powerful Noise Reduction Filters — Temporal, block, mosquito and combing.
• Picture Zooming — Both on main and PIP picture.
• De–interlacing — 3:2 and 2:2 pull–down; 24sf handling.
• Multiple Aspect Ratio Selections — Follow input, follow output, best fit, letterbox and overscan.
• Dual Window Display — Preset picture–in–picture, picture–and–picture and split screens, as well as customized window layouts.
• Advanced EDID Management — For each input and each output.
• Non–Volatile Memory — Saves final settings.
• Firmware Upgrades — Via RS–232.
• Flexible Control Options — Front panel buttons, OSD (on–screen display) via front panel buttons or IR remote (remote control included), Control Application software for use via RS–232.

The SID−X1N is a DGKat™ twisted pair transmitter and step−in commander for computer graphics video, HDMI, DVI, DisplayPort and unbalanced stereo audio signals. The unit includes a “Step−In” button that allows the local source to be routed as the active source on the main display through the main switcher.

PT−101UHD is a high−performance repeater/extender for 4K@60Hz (4:2:0) HDMI and HDCP 2.2 signals. The unit can extend the range up to 20m (66ft) for 4K@60Hz (4:2:0) signals.

• Range Extension — 4K@60Hz (4:2:0) up to 20m (66ft) (15m on the input to the PT–101UHD and 5m on the output).
• Max. Data Rate — 10.2Gbps (3.4Gbps per data channel).
• Re–clocking and Equalization.
• HDMI Output Power Follows Input — There is no power on the output when there is no active input.
• Transparent HDCP 2.2 Support.

VP−733 is a 12−input Presentation Matrix Switcher/Dual Scaler for a wide variety of presentation and multimedia applications. VP−733 has HDMI, DisplayPort, HDBaseT and user−definable (universal) analog video inputs (each can be set as computer graphics, composite video, s−Video (Y/C) or component video). It up−scales or down−scales to selectable output resolutions up to 4K and provides glitch−free switching between sources through fast FTB™ (fade−thru−black) switching technology. Independent Program and Preview outputs are available simultaneously, or the unit can be configured for PIP, with all outputs mirrored. Outputs are available on two HDMI connectors, an HDBaseT, a DP, and a 15−pin−HD computer graphics video connector. Rich audio support is also included, with digital audio embedding and de−embedding, as well as 10 analog stereo inputs and analog, S/PDIF, and speaker outputs.

• PixPerfect™ Scaling Technology — Kramer’s precision pixel mapping and high–quality scaling technology.
• Fast Fade–Thru–Black (FTB™) Switching — Clean and fast, fade to black for smooth, constant sync glitch–free switching.
• K–IIT XL™ Picture–in–Picture Image Insertion Technology — Ultra stable picture–in–picture, picture–and–picture, and split screen capability.
• Dual Scalers — With independent outputs.
• Preview Mode Button — Toggles between the PIP mode and the PREVIEW mode.
• 10 Preview/Program Input Buttons — For switching a selected input to the preview output (in PREVIEW mode) and for switching a selected input to the program output.
• Output Resolutions — Up to 4K@30Hz on the program output, up to 720p on the preview output.
• Scaled Video Outputs — 2 HDMI, 1 DP, 1 HDBaseT and 1 15–pin HD computer graphics video.
• 12 Video Inputs — 4 HDMI, 4 universal analog, 2 DisplayPort, 2 HDBaseT.
• Multiple Computer Graphics Output Resolutions — Including a user–defined output resolution.
• Multiple Aspect Ratio Selections.
• Audio Breakaway & AFV Support.
• Embedded Audio — On the HDMI, HDBaseT and DisplayPort inputs and outputs.
• Built–in Noise Reduction & Picture Enhancement.
• Powerful Audio Features — Via DSP technology including audio equalization, mixing, delay and more.
• Speaker Output — One stereo speaker output, 10W per channel into 8Ω, on a 4–pin terminal block connector.
• Input Auto–Switching & Auto–Scanning.
• Efficient Power–Saving Features.
• Built–in Time Base Corrector — Stabilizes video sources with unstable sync.
• Built–in Proc–Amp — Color, hue, sharpness, contrast, and brightness per input.
• Function Buttons — Blank and Freeze for the preview and program modes, Reset to XGA/720p (to reset the output resolution) and PANEL LOCK.
• Text Overlay Support — via user–friendly software application.
• Firmware Upgrade — Ethernet–based, via a user–friendly software upgrade tool.
• On–Screen Display.
• USB Port — For downloading splash–screen logo and storing/downloading machine configurations via disk–on–key.
• Non–Volatile Memory — Retains last settings after powering off and on.
• Video Processing — Filters and algorithms eliminate picture artifacts.
• Scales & Zooms — Up to 400% of original size.
• Advanced EDID Management.
• Various Control Options — RS–232 serial commands transmitted by a touch screen system, PC, or other serial controller, infrared remote control transmitter, Ethernet using built–in Web pages.

The VM-50AN is a high-performance distribution amplifier for balanced and unbalanced stereo audio signals. It takes one balanced or unbalanced stereo input and distributes the signal simultaneously to ten stereo outputs (five balanced and five unbalanced).

• Balanced/Unbalanced Input Selection.
• S/N Ratio — 84dB (unweighted).
• Level (Gain) Controls.
• Desktop Size — Compact size. 2 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.

The VM-3AN is a high-performance distribution amplifier for balanced stereo audio signals. The unit takes one stereo input and distributes the signal to three identical outputs.

The VA-14 is a high-performance 4-channel mixer for balanced mono audio signals on XLR connectors. The unit inputs four channels of any combination of balanced mic or line level audio signals and outputs two mixed balanced audio and one headphone signal.

• S/N Ratio — Mic in, phones out: 45.3dB; line in, phones out: 83.3dB; line in, line out: 84.3dB; mic in, line out: 64dB.
• Level (Gain) Control — Individual for each input & master and headphone output.
• Phantom Power — 48V DC on each input (individually selectable).
• Desktop Size — Compact size. 2 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.

The PT-102AN is a high-performance audio distribution amplifier for unbalanced stereo signals. The unit takes one stereo input and distributes the signal to two identical stereo outputs.

The 900xl is a high−performance power amplifier for line level stereo audio signals. The unit accepts unbalanced audio signals on either of two RCA or 3.5mm connectors and delivers a speaker output of 10 watts RMS per channel into a 4Ω load.

• High Efficiency — Class D operation.
• S/N Ratio — 60dB.
• Control — Volume & input selection from front panel & RS–232.
• Compact Kramer TOOLS™ — 3 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.

The 900N is a high−performance power amplifier for balanced or unbalanced stereo audio signals. Either input can deliver a speaker output of 10 watts RMS power per channel into a 4Ω load.

• High Efficiency — Class D operation.
• S/N Ratio — 55dB.
• Controls — Volume knob, On LED.
• Special Note — Before turning on the 900N, make sure the volume is turned down to the minimum.
• Compact Kramer TOOLS™ — 3 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.

• Connectors — Terminal blocks (balanced & unbalanced).
• Level (Gain) Control — Independent L & R adjustment while transcoding for both balanced to unbalanced conversion and unbalanced to balanced conversion.
• S/N Ratio — 95dB balanced to unbalanced, 87dB unbalanced to balanced, unweighted.
• Compact Kramer TOOLS™ — 3 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.

The 105A is a high-performance distribution amplifier for unbalanced stereo audio signals. It takes one stereo input and distributes the signal to five identical stereo outputs.

• Level (Gain) Controls.
• S/N Ratio — 80dB (unweighted).
• Compact Kramer TOOLS™ — 3 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.

The 102xl is a high−performance 2−channel mono audio mixer for balanced line level and mic level mono audio signals. The unit mixes two mono inputs and produces a mixed audio output signal.

• S/N Ratio — 91.5dB (line level), 62.5dB (mic level).
• Line or Mic Level — Input selectable.
• Phantom Power — 48V DC (input selectable).
• Level (Gain) Control — Input 1, input 2, and master.
• Compact MultiTOOLS® — 4 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.

VS−21DTP is a high−performance automatic switcher for 4K, HDBaseT, HDMI, HDCP 2.2 video signals. Offering priority and last−connected switching options, it automatically switches according to the selected switching scheme based on active video signal detection. VS−21DTP is a PoE provider that provides power over Ethernet to compatible PoE receivers and it can also receive power from a compatible PoE provider.

• Max. Data Rate — 8.91Gbps (2.97Gbps per data channel).
• Max. Resolution — 4K@60Hz (4:2:0).
• HDCP 2.2 Compliant.
• Supports up to 40m reach at 4K@60Hz (4:2:0).
• Kramer Equalization and re–Klocking Technology.
• HDTV Compatible.
• 3D Pass–Though.
• Bidirectional PoE over HDBaseT

The SL−1N is a master room controller that can operate over Ethernet (LAN) with control ports that include two bidirectional RS−232, two IR and three relay. It controls devices such as scalers, video displays, audio amplifiers, DVD players, sensors, screens, shades, door locks, and lights. Multiple Kramer Ethernet gateways can be used to add remote I/O ports.

The SL−1N includes a KNET™ connector interface which enables access to the master controller from auxiliary room controllers such as control keypads. The SL−1N can also provide power to auxiliary room controllers via the KNET™ connectors.

• 1 Ethernet Port — Connector for IP–enabled devices and control gateways for adding remote I/O ports
• 1 K–NET™ Connector — Enables communication between the master controller and auxiliary room controllers such as control keypads
• K–NET™ Single Link Connection — Enables a single connection for both power and control to auxiliary controllers
• 2 RS–232 Bi–directional Control Ports — Serial control protocol for compatible devices
• 2 IR Emitter Control Ports — Infrared control for compatible devices
• 3 Relay Control Ports — Contact closure control for actions such as rolling up and down screens, drapes, shades, and blinds
• Simultaneous IP Control Communication — With up to 15 IP control clients.
• Kramer K–Config™ Compatible — Intuitive Windows–based configuration application for fast and easy design of room control systems
• Kramer Site–CTRL™ Compatible — Remote customer site control and management over customer's IP network
• IR Sensor and IR Input Ports — Learn commands from IR remotes
• Mini USB Port — For firmware upgrades of technical services

The FC−26 is a PoE−powered control gateway, capable of plug and play deployment over a customer Ethernet LAN for remote control of customer controlled devices via bidirectional RS−232 and IR control connections. Multiple control clients can be IP−connected to the FC−26 control gateway for concurrent control of two RS−232 and four IR controllable devices, such as AV scalers, video displays, audio amplifiers, and DVD players.

• 2 RS–232 Bidirectional Control Ports — Control a device via bidirectional serial control protocols.
• 4 IR Emitter Control Ports — Control a device via IR control protocols.
• 1 Ethernet Control Port — Remote protocol–based control port.
• Built–in Web Pages — Remote browser–based control and support.
• Simultaneous IP Control Communication — With up to 40 IP control clients.
• IR Sensor Port — Learns commands from IR remotes.
• Mini USB Port — For firmware upgrades and local technical services.
• PoE Support — Per IEEE 802.3af standard.


The FC−24ETH is an Ethernet control gateway, capable of plug and play deployment over a customer Ethernet LAN for remote control of customer controlled devices via bidirectional RS−232 or RS−485 serial control connections. Multiple control clients can be IP−connected to the FC−24ETH control gateway for concurrent control of two RS−232 or RS−485 controllable devices, such as AV scalers, video displays, and audio amplifiers.

• 1 RS–485 or RS–232 Selectable Bidirectional Control Port — Controls a device via bidirectional serial control protocols.
• 3 RS–232 Bidirectional Control Ports — Control devices via bidirectional RS–232 serial control protocols.
• 1 Ethernet Control Port — Remote protocol–based control port.
• Built–in Web Pages — Remote browser–based control and support.
• Simultaneous IP Control Communication — With up to 40 IP control clients.
• Mini USB Port — For firmware upgrades and local technical services.
• Easy Installation — Plug & play IP auto–setup deployment for simple and cost–reducing installation.

The FC−22ETH is an Ethernet control gateway, capable of plug and play deployment over customer Ethernet LAN for remote control of customer controlled devices via bidirectional RS−232 or RS−485 serial control connections. Multiple control clients can be IP−connected to the FC−22ETH control gateway for concurrent control of two RS−232 or RS−485 controllable devices, such as AV scalers, video displays, and audio amplifiers.

• 1 RS–485 or RS–232 Selectable Bidirectional Control Port — Controls a device via bi–directional serial control protocols.
• 1 RS–232 Bidirectional Control Port — Controls a device via bidirectional RS–232 serial control protocols.
• 1 Ethernet Control Port — Remote protocol–based control port.
• Built–in Web Pages — Remote browser–based control and support.
• Simultaneous IP Control Communication — With up to 40 IP control clients.
• Mini USB Port — For firmware upgrades and local technical services.
• Easy Installation — Plug & play IP auto–setup deployment for simple and cost–reducing installation.

The 907 is a high−performance power amplifier for line−level stereo audio signals. It accepts a balanced stereo audio signal on a terminal block connector and delivers 40 watts per channel into an 8Ω load.

• High Efficiency — Class D operation.
• Controls — Volume control knob & mute button.
• Gain Control DIP–Switch.
• Mute and On Indicator LEDs.
• Compact MultiTOOLS® — Up to 4 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter

The 907xl is a high−performance power amplifier for line−level stereo audio signals. It accepts a balanced stereo audio signal on a terminal block connector and an unbalanced stereo signal on RCA connectors. It delivers 40 watts per channel into an 8Ω load.

• High Efficiency — Class D operation.
• Controls — 1 volume control knob for each input & mute button.
• Gain Control DIP–Switches.
• Mute and On Indicator LEDs.
• Compact MultiTOOLS® — Up to 4 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.

FC−6 is an RS−232/IR multi−function control gateway, capable of plug and play deployment over a customer Ethernet LAN for remote bidirectional RS−232 and IR emitter control of customer devices. Multiple control clients can be IP−connected to the FC−6 control gateway for concurrent control of two RS−232 or four IR controllable devices, such as AV scalers, video displays, audio amplifiers, and DVD players.

• Dual–Function I/O Ports — Remote IP–Based control of devices connected to the control gateway dual–function I/O ports, with selectable port configuration to bidirectional RS–232 or IR control.
• Multiple IP Connected Clients — Remotely connected over customer Ethernet network, concurrently controlling any devices connected to control gateway I/O ports.
• Easy & Reliable Installation — Plug and Play IP installation with dynamic (DHCP) address resolution and auto device discovery over customer LAN. Resilient powering with USB and optional PSU (not included). Compact, designed for piggy–back installation, such as behind a TV or display, with the ability to draw power from a device USB port.
• Remote Management — Built–in web UI for remote browser–based management and support, by multiple IP–clients over customer LAN. Easy firmware upgrades, either remotely via customer LAN, or locally via device USB port.
• Pico TOOLS™ — Mount 4 units side–by–side in a 1U rack space with the recommended rack adapter.

The FC−28 is a PoE−powered control gateway, capable of plug and play deployment over customer Ethernet LAN for remote control of customer controlled devices via bidirectional RS−232, IR, GPI/O and relay control connections. Multiple control clients can be IP−connected to the FC−28 control gateway for concurrent control of two RS−232,four IR controllable devices, such as AV scalers, video displays, audio amplifiers, DVD players, sensors, screens, shades, door locks, and lighting.

DSP−1 is a digital sound processor that enables the control of individual volume per input, 3−band parametric EQ, selectable HPF (high−pass filters) at 70Hz and master volume via IP.

• 2–Input Mixing with Master Volume.
• 3–Band Parametric Equalizer — Frequency, Q–factor & gain control per band.
• Hi–Pass Filter — Selectable HPF at 70Hz.
• Line–Level Amplifier for Audio Gain and Attenuation.
• Control with Built–In Web Page & RS–232.
• Creates & Saves Presets.
• Highly Cost Effective.
• Professional, Studio Grade Signal Conversion Technology — Includes the latest generation 32–bit advanced Digital Analog Converter architecture to achieve excellent dynamic performance and improved tolerance to clock jitter. Maintains the quality of the original audio signal with selectable sampling rates up to 96 kHz.

• High–performance Amplifier — With built–in DSP and additional balanced stereo line–level output. PA–240Z features flat frequency response, unmatched sonic performance, excellent signal to noise ratio, and extraordinarily low distortion levels.
• Adaptable to Any AV Installation — Switch between Lo–Z and Hi–Z to accommodate any type of loudspeaker installation. Select 1 Channel of 240W into a 70V/100V line or 2 channels of 120W into 4Ω/8Ω.
• Individual Mix Per Output — Each output supports an independent input mix with master volume, 3–band parametric EQ, and selectable high–pass filter. Create one output mix and EQ settings suitable for the venue and another for recording or cascading more amplifiers, powered speakers or subwoofers according to any AV installation requirements.
• Professional, Studio Grade Signal Conversion Technology — Includes the latest generation 32–bit advanced Digital Analog Converter architecture to achieve excellent dynamic performance and improved tolerance to clock jitter. Maintains the quality of the original audio signal with selectable sampling rates up to 96 kHz.
• Durable and Reliable — PA–240Z is immune to failure. It includes layers of protection against over–current, DC voltage at the outputs, high frequency, and over–heating with intelligent, heat–sensitive fans for added protection.
• Flexible Control Options — Control locally via RS–232 serial commands or remotely, via embedded web pages over Ethernet.
• Power Efficient — This super–efficient amplifier includes auto–standby for power saving and cost reducing operation. No need to rely on default auto–standby settings. Adjust your noise floor threshold based on exactly when your amplifier needs to go into sleep mode and when it needs to wake up.
• Easy Installation — ½ 19” size enables mounting in a 1U rack space with the recommended rack adapter.

The VM−24H is a distribution amplifier for HDMI signals. The unit reclocks and equalizes one of two selectable input signals and distributes it to four identical outputs.

• Max. Data Rate — 6.75Gbps (2.25Gbps per graphic channel).
• HDTV Compatible.
• HDCP Compliant.
• HDMI Support — Deep Color, x.v.Color™, Lip Sync, CEC.
• 3D Pass–Through.
• EDID Pass–through — Pass–through algorithm ensures Plug and Play operation for HDMI source and display systems.
• Active Output LED Indicators.
• Control — Front panel, RS–232, IR switching.
• Worldwide Power Supply — 100–240V AC.
• Standard 19” Rack Mount Size — 1U. Rack “ears” included.

The VM−22H is a distribution amplifier for HDMI signals. The unit reclocks and equalizes one of two selectable input signals and distributes it to two identical outputs.

• Max. Data Rate — 6.75Gbps (2.25Gbps per graphic channel).
• HDCP Compliant.
• HDMI Support — Deep Color, x.v.Color™, Lip Sync, CEC.
• 3D Pass–Through.
• EDID Pass–through — Pass–through algorithm ensures Plug and Play operation for HDMI source and display systems.
• Active Output LED Indicators.
• Control — Front panel or IR remote switching.
• Kramer Equalization & re–Klocking™ Technology — Rebuilds the digital signal integrity to travel longer distances.
• Compact DigiTOOLS® — 3 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.

VA−4X is a versatile 4K@60Hz (4:4:4) HDMI multi−channel extender that equalizes and reclocks TMDS data before re−transmitting the signal, thus increasing the HDMI cable range for all 4 outputs. It is a true 4−channel HDMI "Toolbox", with functionality including 4 independent test−pattern generators, chroma sub−sampling down−conversion and EDID management options, and, of course, video extension.

• Extension without Loss of Quality — Kramer Equalization & re–Klocking™ Technology rebuilds the digital signal integrity to travel longer distances. Typically extends 4K@60Hz (4:4:4) signals 20m from point to point (10m on the input and 10m on the output).
• Zero–latency compression — Enables reducing 4K@60Hz resolution from 4:4:4 to 4:2:2 or 4:2:0 chroma sampling on up to four HDMI signals.
• Easy EDID Management — Via a user–friendly software application or OSD menu, select from the following EDID options: default (internal), external (sink) or user defined EDID.
• Content Protection Compatibility — Interoperability between HDCP 2.2 and HDCP 1.4 systems for up to 4 HDMI sources simultaneously.
• Comprehensive Signal Testing — Independent pattern generator on each output with a variety of patterns and resolutions to choose from.
• Local Control and Configuration — Use the OSD menu via front panel buttons for management and control of the EDID, chroma reduction and pattern generator, and for firmware upgrade and factory reset. Convenient USB port for EDID application control and firmware upgrade.
• Easy Installation — Compact MegaTOOLS® fan–less enclosure for surface mounting or side–by–side mounting of 2 units in a 1U rack space with the recommended rack adapter.

The TP−574 is a DGKat™ twisted pair receiver for HDMI, bidirectional RS−232 and infrared signals. The TP−573 converts the input signals to a twisted pair signal and the TP−574 converts it back to HDMI, RS−232 and infrared signals.

• Max. Data Rate — 4.95Gbps (1.65Gbps per graphic channel).
• HDTV Compatible.
• HDCP Compliant.
• HDMI Support — x.v.Color™, Lip Sync, HDMI Uncompressed Audio Channels, Dolby TrueHD, DTS–HD.
• 3D Pass–Through.
• EDID PassThru — Passes EDID signals between the source and display.
• Bidirectional RS–232 & IR Interface. — 38400 max baud rate.
• System Range — Up to 90m (295ft) at 1080i @60hz or up to 70m (230ft) at 1080p @ 60hz when using Kramer DGKat cables. Note: Transmission range depends on the signal resolution, graphics card and display used. If using third–party shielded CAT cables, both ends of the shield must be soldered to the connectors for the products to function properly.
• DGKat™ Signal Integration — Kramer’s unique technology for converting TMDS as well as control and communication to signals that run over twisted pair cables.
• Power Connect System™ — A single connection to the transmitter powers both units.
• Compact DigiTOOLS® — 3 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.
