High-Performance

Description

The first battery-powered loudspeaker from Electro-Voice and the first weatherized model of its type, EVERSE 8 takes advantage of decades of Electro-Voice engineering expertise – along with the latest advancements in technology – to provide a truly portable and truly wireless audio experience at a price and performance level unmatched by current comparable products on the market.

Whether used for live music, vocal reinforcement and/or audio playback, musicians, DJs, production/rental companies, fitness/activity instructors and other professional, amateur and recreational users can all benefit from EVERSE 8’s superior sound quality, user-friendliness and all-in-one PA system design – a concept that opens-up real pro-audio performance for a wider range of users than ever before. EVERSE 8 comes in a black or white finish, adding an aesthetic angle to its versatility.

Features

• Designed to deliver a step up in sound quality for the battery-powered portable PA segment, with high SPL and full-bandwidth coverage
• Compact, lightweight and weatherized design coupled with extended battery life – longer run time for gigs and events, indoors or outdoors
• Flexible all-in-one feature set, including QuickSmart Mobile app and Bluetooth® for best-in-class control and streaming, an onboard mixer and studio-quality effects – a user-friendly and versatile choice for musicians, DJs, fitness/activity instructors, events/gatherings and more

Real Pro-Audio Performance

With a maximum SPL rating of 121 dB and wide, even 100º x 100º coverage, EVERSE 8’s capabilities defy its compact form factor and set uncompromising new benchmarks for its product segment. Core components include an 8” woofer mounted using EV’s patented SST (Signal Synchronized Transducers) port design, and a high-output titanium tweeter mounted onto a custom constant-directivity waveguide. And, as with all Electro-Voice portable loudspeakers, EVERSE 8’s system reliability is verified with extensive music abuse and endurance testing.

Battery-Powered Convenience

EVERSE 8 is powered by a custom-designed high-capacity Li-ion battery pack, fully optimized for audio use and providing plentiful power for up to 12 hours of run time. Protection circuitry reduces the risk of the battery discharging to such a low voltage that it can no longer be recharged – for example, after long periods in storage. Tool-free screws make removing the battery pack effortless. Uncompromising sound quality, unplugged.

IP43-Rated Weatherized Design

In combination with the rugged polypropylene enclosure, use of the included weatherized input cover allows EVERSE 8 to meet the IP43 rating (water resistant for splashes and light rain) when running on battery power and while Bluetooth® streaming. Built-in feet with no-skid rubber pads ensure the system stays put. Bring EVERSE 8 outside for busking, marching band practice, or the backyard BBQ, or wherever a PA is needed, whatever the forecast.

Compact & Lightweight

Every detail of EVERSE 8 is designed to maximize easy lifting and transportation – all while reinforcing EV’s reputation for real-world durability. An ergonomically designed soft-touch handle and premium lightweight construction make it a breeze to move and mount EVERSE 8. Pack it into the optional tote bag and head out to the gig. It’s the all-in-one pro-audio system you can grab to go.

Expandable Functionality

The integrated 12 V DC port provides convenient power from the EVERSE 8 battery, perfect for powering a wireless microphone system such as the Electro-Voice RE3 or R300 (see user manual for details). Attach the optional accessory tray to the top of an EVERSE 8 to secure receiver hardware in place. A charging port is included for mobile devices if a top-up is needed when streaming. Place on a tripod for a longer throw, set long-side down as a stage wedge using the 55° monitor angle, or use upright with the 30° kick-back angle to project up off the performance area. For stereo setups, EVERSE 8 is equipped for Bluetooth® true wireless stereo streaming.

Powered by Dynacord

EVERSE 8 is driven by a high-efficiency Class-D amplifier and DSP module developed in collaboration with the world-class audio electronics engineering team at EV’s sibling brand Dynacord. Pro features include a built in four-channel digital mixer with studio-quality effects and processing, 48 V phantom power, feedback suppression and audio ducking. Between the EV and the D badges, you get the best of both worlds.

Wireless Control & Monitoring

Use the EV QuickSmart Mobile app to adjust all audio, effects and mix functions via your phone or tablet. An intuitive user interface makes it simple to shape your sound to the space, so you can focus on the show.

The Yarden 6-O High Performance On-wall Speaker features a Kevlar(R) woofer, 2nd level cross-over design and multi-tap power transformer for selecting 8Ω (bypassing the transformer) or 70V/100V power settings that are suitable for an array installation.

• Type — 2–way on–wall speaker.
• Woofer — 6.5” Kevlar(R) cone.
• Tweeter — 1” titanium dome.
• Impedance — 8Ω.
• Power Handling — 80W RMS, 220W continuous program.
• Transformer Taps — 70V: 60W /30W/15W/7.5W/Off (Lo–Z); 100V: 60W/30W /15W/Off (Lo–Z).
• Package — 2 speakers (1 pair).

The Yarden IH−1 is an open−back speaker designed for mounting invisibly in the wall. It is designed for infinite baffle environments, high−power handling and excellent acoustic performance.

• Type — In–wall hidden speaker.
• Drive Units — Polypropylene flat membrane, 2" voice coil, double magnet neodymium motor.
• Frequency Response — 120Hz to 20kHz @±3dB.
• Transformer Taps — 8Ω/70V/100V.
• Sensitivity — 83dB, 1W @1m.
• Power Handling — 40W RMS, 90W continuous program.
• Crossover — 2nd level @120Hz, high pass.
• Mounting Brackets — Equipped with special “insert and drop” brackets for quick, easy and intuitive installation.
• Dimensions — Overall: 35cm x 26cm (13.7" x 10.2") W, H; cutout: 32.5cm x 24cm (12.7" x 9.4") W, H; mounting depth: 5.7cm (2.2").
• Weight — 1.6kg (3.5lbs) approx.
• Package — 1 speaker.

The Yarden 8−T High−Performance Ceiling Tile Stereo Speaker features a Kevlar(R) woofer, four pivoting titanium tweeters, complete K−overage ESD™ (Equal Sound Dispersion) design for almost 180 degrees of sound dispersion. It features speech mode to improve intelligibility, music mode for an extra wide frequency response and stereo and mono modes to fit any kind of installation. It also features a magnetically held grill (with two security screws) for time saving installation, 2nd level cross−over design and multi−tap power transformer for selecting 8Ω (bypassing the transformer) or 70V/100V power settings that are suitable for an array installation.

• Type — 2–way ceiling tile speaker.
• Woofer — 8” Kevlar(R) cone.
• Tweeters — Four pivoting 0.75” titanium domes.
• Impedance — Stereo 8Ω, mono 4Ω.
• Stereo/Mono Selector Switch.
• Speech/Music Selector Switch.
• Power Handling — 2 x 40W RMS, 2 x 110W continuous program.
• Transformer Taps — Stereo: 70V: 2 x 30W/15W/7.5W/3.7W, 100V: 2 x 30W/15W/7.5W; Mono: 70V: 60W/30W/15W/7.5W, 100V: 60W/30W/15W.
• UL Certification — UL 1480 & 2043 listed and plenum compliant.
• Package — 1 speaker.

Yarden VT−2 is a revolutionary vibrating transducer speaker that transforms any solid resonant surface into a powerful, high−quality speaker. The compact Yarden VT−2 can be discreetly attached to the surface or underside of any table, wall or door and utilizes vibration to emit sound evenly from that surface. Yarden VT−2 is safe to use on nearly any surface and eliminates the hassle of positioning conventional speakers around a room. The Yarden VT−2 includes a selectable 70V/100V line transformer for Hi or Lo−Z applications.

• Vibrating Transducer — Nearly any surface, wall or table becomes a quality speaker.
• Power Rating — 10W @8Ω.
• Very Compact.
• Easy Versatile Installation — Under the table, on–wall, in–wall.
• Selectable Line Transformer — Choice of 70V/100V using a line transformer, or 8Ω when switching to bypass the transformer.
• Kramer Patent Pending.

Overview

The MuxLab Dante 60W Column Speaker PoE (500220) is a speaker designed with advanced linear sound source technology, each speaker consists of (4) 3-inch ferrite bass drivers with 25mm voice coils. It meets the design requirements of linear sound sources and has broad horizontal directivity and narrow vertical directivity, sending the sound to the target area accurately, avoiding reflection from the ceiling and ground while increases the proportion of direct and reverberation sound to greatly improve speech clarity.

The MuxLab Dante 60W Column Speaker PoE is mainly used in speech sound reinforcement system, works as the main loudspeaker in a multifunctional small conference room, or the supplementary loudspeaker in the medium-sized conference room. Could be used in small music sound reinforcement systems with subwoofer loudspeakers, and can also be used with the latest Dolby surround sound systems as left or right surround, back surround, or ceiling surrounds sound box use.

It supports a variety of installation methods including a convenient U-shaped frame. The special U frame provides two modes: fixed angle and adjustable angle. In the adjustable mode, the adjustment up and down angle is 15 degrees. You can also use the universal NBT717M wall mount frame or a vertical and horizontal multi-angle frame to hoist the speakers.

The MuxLab Dante 60W Column Speaker PoE has a small and exquisite appearance, the cabinet is made of high-quality wood, which restores the original sound. The clean finish on the surface of the cabinet allows the speaker to adapt to different decorative styles. Free software calibration tool available to customize speaker sound settings. The MuxLab Dante 60W Column Speakers are sold in pairs.

The EVID-S4.2T, from Electro-Voice, is a high performance, two-way, full-range, 4"" (102 mm) surface mount speaker with excellent wide, uniform coverage, and outstanding performance. It is designed for background and foreground music, paging, and sound reinforcement, and it's ideal for a wide variety of indoor and outdoor applications, such as restaurants, bars, patios, retail, fitness clubs, hospitality, theme parks, leisure venues, and others. With unparalleled ease-of-installation, sturdy weather resistance, modern and delicate look, and it's flexible mounting options, the EVID-S4.2T is the perfect solution for a wide variety of surface mount applications.

The EVID-S4.2T includes the unique and innovative mounting system, from Electro-Voice, making every installation quick, simple, and reliable. The mounting system allows for 90 degrees of rotation horizontally, and 45 degrees of rotation vertically, and it can be easily installed on walls and ceilings. The mounting system comes already assembled and ready to be used, ready to make any job easier.

The EVID-S4.2T utilizes a 15 W transformer, that offers a selection of 3.7 W (70 V only), 7.5 W or 15 W delivered to the speaker system using either 70 V or 100 V lines. Selection is done with a Euroblock connector on the input panel located on the rear of the speaker.

The EVID-S4.2T has been carefully engineered to resist outdoor environments, without compromising on performance for indoor applications. The full-range speaker is IP54 rated, and its weather-proofing is complemented with exceptional cabinet and grille resistance against sun, salt and moisture.

All EVID-S models are available in black or white, and can be easily painted to match the décor. Transformer versions are also available for constant voltage systems.

The wide range of EVID surface mount speakers has been designed to work together as a complete system in a variety of different surface mount constructions, and to be used in combination with other EVID ceiling and in-wall speakers.

Features

• Innovative mount system is included for quick, simple, and reliable installations.
• Carefully engineered for outdoor environments (IP54), without compromising performance.
• Long throw 4" (102 mm) woofer housed in a fire rated ABS plastic enclosure for extended LF performance down to 75 Hz
• 40 W power handling provides for 103 dB maximum SPL (109 dB peak)
• Sold in pairs

Specifications

• Frequency response (-3 dB): 100 Hz - 20 kHz
• Frequency response (-10 dB): 75 Hz - 20 kHz
• Sensitivity: 86.5 dB2
• Max SPL (calculated): 98.5 dB (104.5 dB Peak)
• Coverage angle: Horizontal 110°, Vertical 110°
• Power handling: 15 W (60 W Peak) Continuous, Pink Noise (100 hours)
• Low Z: Yes
• Nominal impedance: 8Ω
• Minimum impedance: 6Ω
• Recommended High-Pass: 70 Hz (24 dB/octave)
• Input transformer (70V/100V): No
• LF transducer: 4 inch (102 mm)
• HF transducer: 0.75 inch (20 mm)
• Connectors: Captive screws on wall bracket.
• Max. wire size: 12AWG (2.5mm).
• Environmental: IP54 (per IEC-60529)
• Color: Black (RAL 9004) or white (RAL9003)
• Dimensions (HxWxD): 193 mm x 140 mm x 118 mm, (7.6 in x 5.5 in x 4.7 in)
• Net weight: 1.8 kg (4.0 lb)
• Shipping weight (pair): 5.4 kg (11.9 lb)
• Included hardware: Mounting bracket and 4-mm, Allen wrench
• Packaged quantity: 2
