Commercial

This frame with grille is made to accept an 8-inch speaker, 12-inch analog clock, and surface-mount enclosure. It can be mounted to a wall horizontally or vertically. Note: Clock, speaker and backbox are not included.

This frame is made to accept an 8-inch speaker, 12-inch analog clock, and surface-mount enclosure. It can be mounted to a wall horizontally or vertically.

Note: Clock, speaker and backbox are not included.

Frame with grille is made to accept an 8-inch speaker, 12-inch analog clock, and surface-mount enclosure. It can be mounted to a wall horizontally or vertically.

Note: Clock, speaker, and backbox are not included.

This frame is made to accept an 8-inch speaker, 12-inch analog clock, and surface-mount enclosure. It can be mounted to a wall horizontally or vertically.

Note: Clock, speaker and backbox are not included.

Frame with grille is made to accept an 8-inch speaker, 12-inch analog clock, and recessed enclosure. It can be mounted to a wall horizontally or vertically.

Note: Clock, speaker and backbox are not included.

The frame with grille is made to accept an 8-inch speaker, 12-inch analog clock, and recessed enclosure. It can be mounted to a wall horizontally or vertically.

Note: Clock, speaker and backbox not included.

Frame with round grille is made to accept an 8-inch speaker, 12-inch analog clock, and recessed enclosure. It can be mounted to a wall horizontally or vertically.

Note: Clock, speaker and backbox not included.

The frame with grille is made to accept an 8-inch speaker, 12-inch analog clock, and recessed enclosure. It can be mounted to a wall horizontally or vertically.

Note: Clock, speaker and backbox not included.

Description

Bi-directional speaker baffle model BSG-8 for wall is designed for corridors or concourse areas. It includes two grilles on opposite sides to allow sound to radiate from behind and in front of the driver for greater coverage. Side opening for wire access. Steel with white powder epoxy finish. Order speaker separately.

Features

• Material:  Precision formed 20-gauge steel with welded corners
• Grille:  Two pre-mounted steel grilles with welded speaker studs
• Finish:  White
• Size:  11.563 in. square x 4.250 in. deep
• Mounting Aids:  Side opening for wire access (2 in. square) and punched to flush mount a standard E.O. box (not included)

Compliance

• Made in U.S.A.
• Certified U.S. steel

A&E Specifications

The bi-directional baffle for wall or ceiling installation of a single 8 inch driver (not included) shall be Lowell Model No. BSG-8. The box shall be fabricated of 20-gauge steel (11.563 in. square x 4.250 in. projection) with  two pre-mounted grilles, one front and one rear. The assembly shall have a white powder epoxy finish.

The Galil 6−O on−wall speaker features a multi−tap power transformer for selecting 8Ω (bypassing the transformer) or 70V/100V power settings, which are suitable for an array installation. Available in white or black.

• Type — 2–way on–wall speaker.
• Woofer — 6.5” polypropylene cone.
• Tweeter — 1” silk dome.
• Impedance — 8Ω.
• Power Handling — 40W RMS, 110W continuous program.
• Transformer Taps — 70V: 30W/15W/7.5W/3.7W/Off (Lo–Z); 100V: 30W/15W/7.5W/Off (Lo–Z).
• Package Includes — 2 speakers (1 pair).

The Galil 8−C Closed−back Ceiling Speaker features a multi−tap power transformer for selecting 8Ω (bypassing the transformer) or 70V/100V power settings that are suitable for an array installation.

• Type — 2–way coaxial speaker.
• Woofer — 8” polypropylene cone.
• Tweeter — 1” silk dome.
• Impedance — 8Ω.
• Power Handling — 64W RMS, 180W continuous program.
• Transformer Taps — 70V: 64W/32W/16W/8W/4W/Off (Lo–Z); 100V: 64W/32W/16W/8W/Off (Lo–Z).
• UL 1480 & 2043 Listed
• Package Includes — 2 speakers (1 pair), ceiling mounting kit, template and user manual.

The Galil 6−C Closed−back Ceiling Speaker features a multi−tap power transformer for selecting 8Ω (bypassing the transformer) or 70V/100V power settings that are suitable for an array installation.

• Type — 2–way coaxial speaker.
• Woofer — 6.5” polypropylene cone.
• Tweeter — 0.5” Mylar dome.
• Impedance — 8Ω.
• Power Handling — 30W RMS, 80W continuous program.
• Transformer Taps — 70V: 30W/15W/7.5W/3.7W/Off (Lo–Z); 100V: 30W/15W/7.5W/Off (Lo–Z).
• UL 1480 & 2043 Listed
• Package Includes — 2 speakers (1 pair), ceiling mounting kit, template and user manual.

The Galil 6−AW on−wall outdoor speaker features a multi−tap power transformer for selecting 8Ω (bypassing the transformer) or 70V/100V power settings, which are suitable for an array installation. Suitable for outdoor installations and applications. Available in white or black.

• IP 66 Certified — Withstands heavy showers and other outdoor conditions.
• Type — 2–way on–wall speaker.
• Woofer — 6.5” polypropylene cone.
• Tweeter — 1” silk dome.
• Impedance — 8Ω.
• Power Handling — 30W RMS 80W, continuous program.
• Transformer Taps — 70V: 30W/15W/7.5W/3.7W/Off (Lo–Z); 100V: 30W/15W/7.5W/Off (Lo–Z).
• Package Includes — 2 speakers (1 pair), u–mount brackets, grommets.
• Colors Available — Black and white

The Galil 2−C is a 2.5” full−range closed−back speaker with ceramic terminals and a plastic self−extinguishing back−can. It is especially designed to meet the requirements of fire alarm systems in public spaces and is EN 54−24 certified.

• Type — Closed–back ceiling speaker.
• Woofer — 2.5” paper cone.
• Impedance — 8Ω (transformer tap in off position).
• Power Handling — 10W RMS, 30W continuous program.
• Transformer Taps — 70V — 3W/1.5W/0.75W/8Ω/10W/Off (Lo–Z); 100V — 6W/3W/1.5W/8Ω/10W, Off (Lo–Z).
• Packaging — These are priced individually and can be sold individually. (Full carton size is 18 speakers)

The Galil 6−CO is a pair of two−way open−back 8Ω speakers designed for mounting in the ceiling. The speakers feature a multi−tap power transformer for selecting direct 8Ω (bypassing the transformer) or 70V/100V power settings suitable for distributed installation.

• Type — 2–way coaxial round open–back ceiling speaker with infinite baffle design.
• Woofer — 6.5" polypropylene cone with rubber surround.
• Tweeter — 0.5" Mylar.
• Frequency Response — 60Hz to 20kHz.
• Impedance — 8Ω.
• Sensitivity — (SPL) 87dB (1W @1m with 1kHz).
• Recommended Power — RMS 30W, 80W max.
• Grill — White baffle aluminum grills.
• Package — 2 speakers (1 pair), template and user manual.

The Galil 8−CO is a pair of two−way, open−back, 8Ω speakers designed for mounting in the ceiling. The speakers feature a multi−tap power transformer for selecting 8Ω or 70V/100V power settings suitable for array installation.

• Type — 2–way coaxial speaker.
• Woofer — 8” polypropylene cone.
• Tweeter — 1” silk dome.
• Frequency Response — 60Hz to 20kHz @ ±3dB.
• Impedance — 8Ω.
• Power Handling — 50W RMS, 140W continuous program.
• Transformer Taps — 70V: 50W/25W/12W/6W/Off (Lo–Z); 100V: 50W/25W/12W/Off (Lo–Z).
• Package Includes — 2 speakers (1 pair), cutout template and user manual.
• Mounting Bracket (Optional) — SKIC–8.

The Galil 4−CO is a pair of two−way, open−back, 8Ω speakers designed for mounting in the ceiling. The speakers feature a multi−tap power transformer for selecting 8Ω or 70V/100V power settings suitable for array installation.

• Type — 2–way coaxial speaker.
• Woofer — 4" polypropylene cone.
• Tweeter — 0.5” Mylar dome.
• Frequency Response — 80Hz to 20kHz@ ±3dB.
• Impedance — 8Ω.
• Power Handling — 15W RMS, 40W continuous program.
• Transformer Taps — 70V: 15W/7.5W/3.7W/Off (Lo–Z); 100V: 15W/7.5W/Off (Lo–Z).
• Package Includes — 2 speakers (1 pair), cutout template and user manual.

The Galil 4−C Closed−back Compact Ceiling Speaker features a multi−tap power transformer for selecting 8Ω (bypassing the transformer) or 70V/100V power settings that are suitable for an array installation. The Galil 4−CO open−back version is also available.

• Type — 2–way coaxial speaker.
• Woofer — 4” polypropylene cone.
• Tweeter — 0.5” Mylar dome.
• Impedance — 8Ω.
• Power Handling — 30W RMS, 80W continuous program.
• Transformer Taps — 70V: 30W/15W/7.5W/3.7W/Off (Lo–Z); 100V: 30W/15W/7.5W/Off (Lo–Z).
• UL 1480 & 2043 Listed
• Package Includes — 2 speakers (1 pair), ceiling mounting kit, template and user manual.
• Installation Dimensions — External diameter: 19.5cm (7.68"); cutout diameter: 16.7cm (6.57")
